| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C09_003T01_9000006442_50335cztM0_level2.fits | modeM0/AS1C09_003T01_9000006442_50335cztM0_level2_quad_clean.evt |
| Size (bytes) | 697,268,160 | 78,312,960 |
| Size | 665.0 MB | 74.7 MB |
| Events in quadrant A | 4,950,365 | 563,350 |
| Events in quadrant B | 3,549,935 | 621,999 |
| Events in quadrant C | 6,131,568 | 471,954 |
| Events in quadrant D | 10,711,034 | 291,869 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18858 | 1 |
| B | 0 | 14724 | 1 |
| C | 0 | 22407 | 1 |
| D | 0 | 35950 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6042 | 349 | 5.776233% |
| B | 6043 | 177 | 2.929009% |
| C | 6043 | 1024 | 16.945226% |
| D | 6043 | 2946 | 48.750621% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7027 | 6042 | 189 | 189 | 2.69% | 3.13% |  |
| B | 7028 | 6043 | 65 | 65 | 0.92% | 1.08% |  |
| C | 7028 | 6044 | 890 | 890 | 12.66% | 14.73% |  |
| D | 7028 | 6043 | 2907 | 2907 | 41.36% | 48.11% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 4 | 527013 | 3346.7 | 638 | 622 | 157.3 |
| A | 3 | 231 | 390929 | 2481.5 | 638 | 622 | 157.3 |
| A | 8 | 248 | 350896 | 2226.98 | 638 | 622 | 157.3 |
| B | 0 | 198 | 262624 | 1934.7 | 636 | 613 | 135.4 |
| B | 1 | 238 | 90024 | 660.22 | 636 | 613 | 135.4 |
| B | 0 | 213 | 71949 | 526.75 | 636 | 613 | 135.4 |
| C | 15 | 127 | 1155908 | 7076.28 | 586 | 579 | 163.3 |
| C | 15 | 232 | 867271 | 5308.4 | 586 | 579 | 163.3 |
| C | 0 | 208 | 687055 | 4204.6 | 586 | 579 | 163.3 |
| D | 7 | 61 | 4962581 | 37969.15 | 462 | 447 | 130.7 |
| D | 11 | 245 | 1023807 | 7830.52 | 462 | 447 | 130.7 |
| D | 15 | 154 | 456553 | 3490.02 | 462 | 447 | 130.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
