| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_001T01_9000006450_50730cztM0_level2.fits | modeM0/AS1C07_001T01_9000006450_50730cztM0_level2_quad_clean.evt |
| Size (bytes) | 651,159,360 | 97,542,720 |
| Size | 621.0 MB | 93.0 MB |
| Events in quadrant A | 5,090,578 | 657,666 |
| Events in quadrant B | 3,762,935 | 732,306 |
| Events in quadrant C | 9,955,635 | 475,468 |
| Events in quadrant D | 4,729,566 | 580,331 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 146 | 0 |
| B | 0 | 146 | 0 |
| C | 0 | 146 | 0 |
| D | 0 | 146 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20498 | 22 |
| B | 0 | 16468 | 34 |
| C | 0 | 34705 | 48 |
| D | 0 | 19523 | 30 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7289 | 284 | 3.896282% |
| B | 7285 | 74 | 1.015786% |
| C | 7287 | 2168 | 29.751612% |
| D | 7283 | 379 | 5.203899% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7298 | 7297 | 265 | 265 | 3.63% | 3.63% |  |
| B | 7298 | 7294 | 39 | 39 | 0.53% | 0.53% |  |
| C | 7298 | 7296 | 1878 | 1878 | 25.73% | 25.74% |  |
| D | 7298 | 7294 | 363 | 363 | 4.97% | 4.98% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 80 | 1419578 | 7629.28 | 749 | 733 | 186.0 |
| A | 5 | 240 | 94901 | 506.35 | 749 | 733 | 186.0 |
| A | 0 | 31 | 93149 | 496.93 | 749 | 733 | 186.0 |
| B | 8 | 128 | 131392 | 807.81 | 755 | 727 | 161.8 |
| B | 4 | 216 | 93567 | 573.97 | 755 | 727 | 161.8 |
| B | 0 | 213 | 85696 | 525.31 | 755 | 727 | 161.8 |
| C | 15 | 179 | 2773913 | 15847.14 | 639 | 632 | 175.0 |
| C | 5 | 10 | 2576296 | 14717.91 | 639 | 632 | 175.0 |
| C | 9 | 38 | 697065 | 3979.57 | 639 | 632 | 175.0 |
| D | 1 | 47 | 706963 | 3597.74 | 708 | 683 | 196.3 |
| D | 2 | 249 | 325999 | 1657.13 | 708 | 683 | 196.3 |
| D | 7 | 96 | 179591 | 911.34 | 708 | 683 | 196.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
