| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_001T01_9000006450_50850cztM0_level2.fits | modeM0/AS1C07_001T01_9000006450_50850cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,610,225,280 | 275,852,160 |
| Size | 1.5 GB | 263.1 MB |
| Events in quadrant A | 10,979,408 | 1,836,237 |
| Events in quadrant B | 12,922,433 | 1,965,001 |
| Events in quadrant C | 17,220,349 | 1,577,632 |
| Events in quadrant D | 16,908,164 | 1,568,546 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 414 | 0 |
| B | 0 | 414 | 0 |
| C | 0 | 414 | 0 |
| D | 0 | 414 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 46759 | 3 |
| B | 0 | 52056 | 3 |
| C | 0 | 65262 | 3 |
| D | 0 | 64719 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 20383 | 267 | 1.309915% |
| B | 20383 | 898 | 4.405632% |
| C | 20384 | 2506 | 12.293956% |
| D | 20384 | 1617 | 7.932692% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 21488 | 20386 | 134 | 134 | 0.62% | 0.66% |  |
| B | 21488 | 20386 | 518 | 518 | 2.41% | 2.54% |  |
| C | 21489 | 20387 | 1628 | 1628 | 7.58% | 7.99% |  |
| D | 21489 | 20387 | 1348 | 1348 | 6.27% | 6.61% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 249 | 506892 | 943.39 | 2166 | 2105 | 535.1 |
| A | 4 | 191 | 339136 | 629.88 | 2166 | 2105 | 535.1 |
| A | 5 | 240 | 279223 | 517.9 | 2166 | 2105 | 535.1 |
| B | 10 | 44 | 1622027 | 3579.16 | 2129 | 2053 | 452.6 |
| B | 5 | 172 | 1357704 | 2995.16 | 2129 | 2053 | 452.6 |
| B | 8 | 128 | 318854 | 699.94 | 2129 | 2053 | 452.6 |
| C | 4 | 210 | 2422937 | 4394.86 | 2007 | 1987 | 550.9 |
| C | 15 | 229 | 1725272 | 3128.36 | 2007 | 1987 | 550.9 |
| C | 4 | 5 | 718181 | 1300.14 | 2007 | 1987 | 550.9 |
| D | 2 | 216 | 1096592 | 1930.59 | 2027 | 1954 | 567.0 |
| D | 2 | 249 | 1089884 | 1918.76 | 2027 | 1954 | 567.0 |
| D | 2 | 153 | 822252 | 1446.74 | 2027 | 1954 | 567.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
