| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_001T02_9000006452_50995cztM0_level2.fits | modeM0/AS1C07_001T02_9000006452_50995cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,492,796,160 | 180,815,040 |
| Size | 1.4 GB | 172.4 MB |
| Events in quadrant A | 10,268,176 | 1,240,333 |
| Events in quadrant B | 10,933,293 | 1,306,307 |
| Events in quadrant C | 15,796,493 | 1,009,895 |
| Events in quadrant D | 17,168,734 | 939,293 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 286 | 0 |
| B | 0 | 286 | 0 |
| C | 0 | 286 | 0 |
| D | 0 | 286 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 40433 | 1 |
| B | 0 | 42549 | 1 |
| C | 0 | 56652 | 1 |
| D | 0 | 60924 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 14158 | 706 | 4.986580% |
| B | 14159 | 1127 | 7.959602% |
| C | 14159 | 2947 | 20.813617% |
| D | 14159 | 2976 | 21.018434% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 14502 | 14158 | 601 | 601 | 4.14% | 4.24% |  |
| B | 14503 | 14159 | 764 | 764 | 5.27% | 5.40% |  |
| C | 14503 | 14159 | 2515 | 2515 | 17.34% | 17.76% |  |
| D | 14503 | 14159 | 2874 | 2874 | 19.82% | 20.30% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 43 | 778169 | 2162.96 | 1450 | 1413 | 359.1 |
| A | 4 | 249 | 703969 | 1956.35 | 1450 | 1413 | 359.1 |
| A | 3 | 130 | 604341 | 1678.92 | 1450 | 1413 | 359.1 |
| B | 4 | 81 | 1230945 | 4031.6 | 1429 | 1375 | 305.0 |
| B | 12 | 32 | 913242 | 2989.9 | 1429 | 1375 | 305.0 |
| B | 1 | 223 | 729556 | 2387.61 | 1429 | 1375 | 305.0 |
| C | 13 | 3 | 2445334 | 6790.24 | 1305 | 1297 | 359.9 |
| C | 15 | 147 | 1682890 | 4671.95 | 1305 | 1297 | 359.9 |
| C | 1 | 44 | 1462990 | 4061.0 | 1305 | 1297 | 359.9 |
| D | 15 | 184 | 4428690 | 12139.21 | 1302 | 1256 | 364.7 |
| D | 7 | 126 | 1436442 | 3935.02 | 1302 | 1256 | 364.7 |
| D | 10 | 181 | 1101316 | 3016.16 | 1302 | 1256 | 364.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
