| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_001T01_9000006454_51158cztM0_level2.fits | modeM0/AS1C07_001T01_9000006454_51158cztM0_level2_quad_clean.evt |
| Size (bytes) | 636,180,480 | 96,638,400 |
| Size | 606.7 MB | 92.2 MB |
| Events in quadrant A | 6,926,180 | 619,874 |
| Events in quadrant B | 5,297,878 | 651,511 |
| Events in quadrant C | 6,685,446 | 585,694 |
| Events in quadrant D | 4,130,392 | 609,583 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25158 | 2 |
| B | 0 | 20375 | 2 |
| C | 0 | 24387 | 2 |
| D | 0 | 17018 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6586 | 627 | 9.520194% |
| B | 6586 | 486 | 7.379289% |
| C | 6586 | 843 | 12.799879% |
| D | 6586 | 122 | 1.852414% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7561 | 6586 | 637 | 637 | 8.42% | 9.67% |  |
| B | 7561 | 6586 | 340 | 340 | 4.50% | 5.16% |  |
| C | 7561 | 6586 | 757 | 757 | 10.01% | 11.49% |  |
| D | 7561 | 6587 | 118 | 118 | 1.56% | 1.79% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 3 | 1658274 | 9600.96 | 689 | 672 | 172.6 |
| A | 12 | 80 | 1317975 | 7629.92 | 689 | 672 | 172.6 |
| A | 14 | 254 | 464633 | 2687.3 | 689 | 672 | 172.6 |
| B | 10 | 60 | 665086 | 4595.45 | 678 | 655 | 144.6 |
| B | 0 | 197 | 462322 | 3193.06 | 678 | 655 | 144.6 |
| B | 5 | 172 | 275591 | 1901.56 | 678 | 655 | 144.6 |
| C | 10 | 171 | 2539686 | 13642.87 | 667 | 660 | 186.1 |
| C | 13 | 3 | 413513 | 2218.37 | 667 | 660 | 186.1 |
| C | 4 | 12 | 223520 | 1197.49 | 667 | 660 | 186.1 |
| D | 6 | 42 | 329503 | 1690.65 | 688 | 663 | 194.5 |
| D | 8 | 176 | 270523 | 1387.42 | 688 | 663 | 194.5 |
| D | 2 | 216 | 190589 | 976.46 | 688 | 663 | 194.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
