| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C09_011T05_9000006474_52273cztM0_level2.fits | modeM0/AS1C09_011T05_9000006474_52273cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,358,303,040 | 120,712,320 |
| Size | 1.3 GB | 115.1 MB |
| Events in quadrant A | 7,430,997 | 937,614 |
| Events in quadrant B | 9,181,348 | 1,045,889 |
| Events in quadrant C | 23,493,786 | 83,872 |
| Events in quadrant D | 9,321,255 | 825,134 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 30014 | 25 |
| B | 0 | 34926 | 15 |
| C | 0 | 77289 | 21 |
| D | 0 | 35602 | 3 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 222 | 0 |
| B | 0 | 222 | 0 |
| C | 0 | 222 | 0 |
| D | 0 | 222 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 0 |
| B | 0 | 1 | 0 |
| C | 0 | 1 | 0 |
| D | 0 | 1 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 11004 | 825 | 7.497274% |
| B | 11004 | 522 | 4.743730% |
| C | 11005 | 10165 | 92.367106% |
| D | 11006 | 1178 | 10.703253% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 16681 | 11006 | 662 | 662 | 3.97% | 6.01% |  |
| B | 16681 | 11007 | 292 | 292 | 1.75% | 2.65% |  |
| C | 16681 | 11007 | 7746 | 7746 | 46.44% | 70.37% |  |
| D | 16682 | 11009 | 785 | 785 | 4.71% | 7.13% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 7 | 206 | 2038003 | 7504.76 | 1090 | 1063 | 271.4 |
| A | 4 | 249 | 173290 | 634.54 | 1090 | 1063 | 271.4 |
| A | 15 | 250 | 129899 | 474.67 | 1090 | 1063 | 271.4 |
| B | 10 | 254 | 1432321 | 6126.6 | 1108 | 1071 | 233.6 |
| B | 4 | 171 | 1079816 | 4617.67 | 1108 | 1071 | 233.6 |
| B | 7 | 0 | 896790 | 3834.21 | 1108 | 1071 | 233.6 |
| C | 15 | 158 | 10841681 | 98302.4 | 390 | 386 | 110.3 |
| C | 15 | 178 | 7692315 | 69745.82 | 390 | 386 | 110.3 |
| C | 15 | 224 | 2410207 | 21850.82 | 390 | 386 | 110.3 |
| D | 15 | 78 | 1060454 | 3665.81 | 1022 | 977 | 289.0 |
| D | 15 | 42 | 723755 | 2500.83 | 1022 | 977 | 289.0 |
| D | 12 | 18 | 631039 | 2180.03 | 1022 | 977 | 289.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
