| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C09_011T08_9000006482_52877cztM0_level2.fits | modeM0/AS1C09_011T08_9000006482_52877cztM0_level2_quad_clean.evt |
| Size (bytes) | 854,424,000 | 72,843,840 |
| Size | 814.8 MB | 69.5 MB |
| Events in quadrant A | 9,780,862 | 320,345 |
| Events in quadrant B | 8,143,146 | 466,095 |
| Events in quadrant C | 6,581,365 | 481,227 |
| Events in quadrant D | 6,647,772 | 507,495 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 33267 | 1 |
| B | 0 | 28466 | 1 |
| C | 0 | 23860 | 1 |
| D | 0 | 23977 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6150 | 3050 | 49.593496% |
| B | 6150 | 1875 | 30.487805% |
| C | 6151 | 1076 | 17.493091% |
| D | 6150 | 604 | 9.821138% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7015 | 6150 | 2758 | 2758 | 39.32% | 44.85% |  |
| B | 7015 | 6150 | 1527 | 1527 | 21.77% | 24.83% |  |
| C | 7016 | 6151 | 838 | 838 | 11.94% | 13.62% |  |
| D | 7015 | 6150 | 545 | 545 | 7.77% | 8.86% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 191 | 7380574 | 63105.32 | 469 | 457 | 116.9 |
| A | 12 | 80 | 116681 | 993.8 | 469 | 457 | 116.9 |
| A | 15 | 174 | 92389 | 786.08 | 469 | 457 | 116.9 |
| B | 8 | 3 | 5363822 | 45278.96 | 564 | 545 | 118.4 |
| B | 4 | 81 | 143285 | 1205.07 | 564 | 545 | 118.4 |
| B | 5 | 200 | 75370 | 631.7 | 564 | 545 | 118.4 |
| C | 2 | 12 | 2251971 | 13831.94 | 586 | 578 | 162.8 |
| C | 7 | 80 | 755173 | 4636.02 | 586 | 578 | 162.8 |
| C | 15 | 224 | 480838 | 2950.58 | 586 | 578 | 162.8 |
| D | 8 | 176 | 2234677 | 12602.31 | 618 | 589 | 177.3 |
| D | 8 | 48 | 383492 | 2159.93 | 618 | 589 | 177.3 |
| D | 3 | 12 | 381214 | 2147.08 | 618 | 589 | 177.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
