| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_003T01_9000006486_52961cztM0_level2.fits | modeM0/AS1A13_003T01_9000006486_52961cztM0_level2_quad_clean.evt |
| Size (bytes) | 790,632,000 | 83,704,320 |
| Size | 754.0 MB | 79.8 MB |
| Events in quadrant A | 10,298,564 | 386,302 |
| Events in quadrant B | 4,354,495 | 668,858 |
| Events in quadrant C | 4,518,561 | 580,483 |
| Events in quadrant D | 9,593,658 | 446,996 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 35009 | 1 |
| B | 0 | 17372 | 1 |
| C | 0 | 18138 | 1 |
| D | 0 | 33058 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6479 | 2871 | 44.312394% |
| B | 6479 | 368 | 5.679889% |
| C | 6480 | 395 | 6.095679% |
| D | 6480 | 1548 | 23.888889% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7624 | 6479 | 2669 | 2669 | 35.01% | 41.19% |  |
| B | 7624 | 6480 | 267 | 267 | 3.50% | 4.12% |  |
| C | 7625 | 6481 | 341 | 341 | 4.47% | 5.26% |  |
| D | 7625 | 6481 | 1433 | 1433 | 18.79% | 22.11% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 191 | 7201833 | 53897.0 | 535 | 523 | 133.6 |
| A | 4 | 249 | 607263 | 4541.04 | 535 | 523 | 133.6 |
| A | 0 | 8 | 202695 | 1513.12 | 535 | 523 | 133.6 |
| B | 10 | 63 | 858998 | 5934.62 | 675 | 653 | 144.6 |
| B | 10 | 254 | 414899 | 2864.11 | 675 | 653 | 144.6 |
| B | 5 | 185 | 139251 | 958.27 | 675 | 653 | 144.6 |
| C | 15 | 147 | 594153 | 3352.5 | 649 | 645 | 177.0 |
| C | 13 | 3 | 551673 | 3112.54 | 649 | 645 | 177.0 |
| C | 7 | 80 | 355795 | 2006.1 | 649 | 645 | 177.0 |
| D | 8 | 176 | 3327574 | 19610.0 | 589 | 561 | 169.7 |
| D | 2 | 62 | 2036424 | 11999.74 | 589 | 561 | 169.7 |
| D | 15 | 78 | 1380985 | 8136.46 | 589 | 561 | 169.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
