| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_003T01_9000006486_53145cztM0_level2.fits | modeM0/AS1A13_003T01_9000006486_53145cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,732,881,600 | 230,843,520 |
| Size | 1.6 GB | 220.1 MB |
| Events in quadrant A | 11,852,674 | 1,541,325 |
| Events in quadrant B | 11,709,392 | 1,759,029 |
| Events in quadrant C | 21,377,936 | 1,223,150 |
| Events in quadrant D | 17,818,549 | 1,226,060 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 48107 | 10 |
| B | 0 | 47328 | 3 |
| C | 0 | 76110 | 3 |
| D | 0 | 65549 | 4 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 366 | 0 |
| B | 0 | 366 | 0 |
| C | 0 | 366 | 0 |
| D | 0 | 366 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 17884 | 1495 | 8.359427% |
| B | 17997 | 398 | 2.211480% |
| C | 17997 | 4038 | 22.437073% |
| D | 17997 | 3007 | 16.708340% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 19637 | 17886 | 1342 | 1342 | 6.83% | 7.50% |  |
| B | 19637 | 17998 | 224 | 224 | 1.14% | 1.24% |  |
| C | 19637 | 17998 | 3507 | 3507 | 17.86% | 19.49% |  |
| D | 19636 | 17997 | 2886 | 2886 | 14.70% | 16.04% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 191 | 2070061 | 4678.71 | 1785 | 1743 | 442.1 |
| A | 0 | 8 | 1098780 | 2481.59 | 1785 | 1743 | 442.1 |
| A | 7 | 206 | 352946 | 794.45 | 1785 | 1743 | 442.1 |
| B | 10 | 254 | 1784971 | 4617.92 | 1841 | 1775 | 386.1 |
| B | 4 | 81 | 802021 | 2072.39 | 1841 | 1775 | 386.1 |
| B | 2 | 249 | 484975 | 1251.34 | 1841 | 1775 | 386.1 |
| C | 15 | 224 | 4563903 | 9869.44 | 1671 | 1651 | 462.3 |
| C | 15 | 157 | 3334893 | 7210.74 | 1671 | 1651 | 462.3 |
| C | 1 | 241 | 1607797 | 3474.55 | 1671 | 1651 | 462.3 |
| D | 15 | 125 | 7082608 | 14157.44 | 1694 | 1614 | 500.2 |
| D | 3 | 12 | 550011 | 1096.44 | 1694 | 1614 | 500.2 |
| D | 2 | 153 | 451869 | 900.22 | 1694 | 1614 | 500.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
