| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C09_011T06_9000006490_53192cztM0_level2.fits | modeM0/AS1C09_011T06_9000006490_53192cztM0_level2_quad_clean.evt |
| Size (bytes) | 830,194,560 | 72,521,280 |
| Size | 791.7 MB | 69.2 MB |
| Events in quadrant A | 3,196,821 | 604,317 |
| Events in quadrant B | 3,660,289 | 635,785 |
| Events in quadrant C | 7,139,774 | 513,977 |
| Events in quadrant D | 16,251,264 | 6,569 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14146 | 1 |
| B | 0 | 15266 | 1 |
| C | 0 | 25561 | 1 |
| D | 0 | 52519 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6224 | 54 | 0.867609% |
| B | 6225 | 196 | 3.148594% |
| C | 6225 | 927 | 14.891566% |
| D | 6225 | 6171 | 99.132530% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7354 | 6225 | 42 | 42 | 0.57% | 0.67% |  |
| B | 7355 | 6225 | 182 | 182 | 2.47% | 2.92% |  |
| C | 7355 | 6225 | 925 | 925 | 12.58% | 14.86% |  |
| D | 7354 | 6224 | 5987 | 5987 | 81.41% | 96.19% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 80 | 129201 | 790.75 | 647 | 631 | 162.6 |
| A | 0 | 8 | 125576 | 768.45 | 647 | 631 | 162.6 |
| A | 8 | 249 | 95340 | 582.49 | 647 | 631 | 162.6 |
| B | 1 | 255 | 664648 | 4902.43 | 640 | 618 | 135.4 |
| B | 10 | 247 | 89166 | 653.74 | 640 | 618 | 135.4 |
| B | 12 | 32 | 56912 | 415.61 | 640 | 618 | 135.4 |
| C | 15 | 224 | 2531962 | 15169.0 | 603 | 597 | 166.9 |
| C | 1 | 241 | 1357482 | 8131.02 | 603 | 597 | 166.9 |
| C | 10 | 22 | 268505 | 1605.42 | 603 | 597 | 166.9 |
| D | 15 | 125 | 15106638 | 283157.14 | 179 | 170 | 53.4 |
| D | 2 | 249 | 97243 | 1819.54 | 179 | 170 | 53.4 |
| D | 3 | 12 | 71821 | 1343.02 | 179 | 170 | 53.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
