| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C09_011T09_9000006494_53422cztM0_level2.fits | modeM0/AS1C09_011T09_9000006494_53422cztM0_level2_quad_clean.evt |
| Size (bytes) | 752,362,560 | 75,847,680 |
| Size | 717.5 MB | 72.3 MB |
| Events in quadrant A | 3,969,218 | 586,382 |
| Events in quadrant B | 6,366,267 | 506,592 |
| Events in quadrant C | 12,659,729 | 247,011 |
| Events in quadrant D | 4,376,318 | 524,601 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16108 | 1 |
| B | 0 | 23006 | 1 |
| C | 0 | 41761 | 1 |
| D | 0 | 17310 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6176 | 238 | 3.853627% |
| B | 6176 | 1389 | 22.490285% |
| C | 6176 | 3787 | 61.318005% |
| D | 6177 | 310 | 5.018617% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7041 | 6176 | 197 | 197 | 2.80% | 3.19% |  |
| B | 7041 | 6176 | 1095 | 1095 | 15.55% | 17.73% |  |
| C | 7040 | 6175 | 3791 | 3791 | 53.85% | 61.39% |  |
| D | 7042 | 6177 | 302 | 302 | 4.29% | 4.89% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 63 | 438139 | 2716.34 | 647 | 633 | 161.1 |
| A | 15 | 174 | 359804 | 2229.98 | 647 | 633 | 161.1 |
| A | 0 | 8 | 156488 | 967.66 | 647 | 633 | 161.1 |
| B | 4 | 206 | 3179116 | 25711.57 | 580 | 561 | 123.6 |
| B | 14 | 167 | 236673 | 1909.93 | 580 | 561 | 123.6 |
| B | 10 | 28 | 172880 | 1393.9 | 580 | 561 | 123.6 |
| C | 1 | 241 | 7624507 | 67750.96 | 412 | 408 | 112.5 |
| C | 9 | 38 | 1605111 | 14260.07 | 412 | 408 | 112.5 |
| C | 15 | 224 | 1204359 | 10698.82 | 412 | 408 | 112.5 |
| D | 12 | 1 | 892557 | 5029.36 | 623 | 592 | 177.4 |
| D | 2 | 249 | 235023 | 1321.84 | 623 | 592 | 177.4 |
| D | 10 | 172 | 218197 | 1226.97 | 623 | 592 | 177.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
