| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_004T04_9000006500_53516cztM0_level2.fits | modeM0/AS1A14_004T04_9000006500_53516cztM0_level2_quad_clean.evt |
| Size (bytes) | 749,318,400 | 75,424,320 |
| Size | 714.6 MB | 71.9 MB |
| Events in quadrant A | 8,685,309 | 432,088 |
| Events in quadrant B | 5,263,113 | 558,316 |
| Events in quadrant C | 9,227,375 | 360,337 |
| Events in quadrant D | 4,101,019 | 516,706 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 29931 | 6 |
| B | 0 | 19742 | 1 |
| C | 0 | 31481 | 1 |
| D | 0 | 16371 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5951 | 1830 | 30.751134% |
| B | 5952 | 771 | 12.953629% |
| C | 5952 | 2379 | 39.969758% |
| D | 5952 | 308 | 5.174731% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6886 | 5952 | 1502 | 1502 | 21.81% | 25.24% |  |
| B | 6887 | 5953 | 617 | 617 | 8.96% | 10.36% |  |
| C | 6887 | 5953 | 1929 | 1929 | 28.01% | 32.40% |  |
| D | 6887 | 5953 | 265 | 265 | 3.85% | 4.45% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 62 | 3480348 | 24304.75 | 570 | 556 | 143.2 |
| A | 3 | 63 | 1397881 | 9759.67 | 570 | 556 | 143.2 |
| A | 15 | 174 | 1367853 | 9549.94 | 570 | 556 | 143.2 |
| B | 5 | 172 | 1331445 | 10173.45 | 612 | 590 | 130.8 |
| B | 4 | 81 | 412558 | 3149.2 | 612 | 590 | 130.8 |
| B | 4 | 171 | 394110 | 3008.18 | 612 | 590 | 130.8 |
| C | 1 | 241 | 2292444 | 16540.05 | 498 | 495 | 138.6 |
| C | 15 | 224 | 2266743 | 16354.57 | 498 | 495 | 138.6 |
| C | 7 | 64 | 1304996 | 9414.04 | 498 | 495 | 138.6 |
| D | 2 | 153 | 471831 | 2647.24 | 623 | 595 | 178.0 |
| D | 2 | 16 | 328870 | 1844.14 | 623 | 595 | 178.0 |
| D | 3 | 12 | 207020 | 1159.63 | 623 | 595 | 178.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
