| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_004T05_9000006502_53560cztM0_level2.fits | modeM0/AS1A14_004T05_9000006502_53560cztM0_level2_quad_clean.evt |
| Size (bytes) | 902,594,880 | 74,062,080 |
| Size | 860.8 MB | 70.6 MB |
| Events in quadrant A | 9,218,163 | 458,551 |
| Events in quadrant B | 3,449,762 | 674,667 |
| Events in quadrant C | 7,775,689 | 488,486 |
| Events in quadrant D | 12,463,809 | 166,415 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 31839 | 1 |
| B | 0 | 14764 | 1 |
| C | 0 | 27595 | 1 |
| D | 0 | 41491 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6503 | 2149 | 33.046286% |
| B | 6504 | 83 | 1.276138% |
| C | 6504 | 1447 | 22.247847% |
| D | 6504 | 4793 | 73.693112% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7338 | 6505 | 1950 | 1950 | 26.57% | 29.98% |  |
| B | 7339 | 6506 | 40 | 40 | 0.55% | 0.61% |  |
| C | 7339 | 6506 | 1403 | 1403 | 19.12% | 21.56% |  |
| D | 7339 | 6506 | 3502 | 3502 | 47.72% | 53.83% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 63 | 2690812 | 17444.74 | 611 | 595 | 154.2 |
| A | 15 | 174 | 1846452 | 11969.48 | 611 | 595 | 154.2 |
| A | 3 | 62 | 861360 | 5581.64 | 611 | 595 | 154.2 |
| B | 10 | 247 | 155258 | 1039.54 | 694 | 670 | 148.7 |
| B | 0 | 213 | 147925 | 990.23 | 694 | 670 | 148.7 |
| B | 15 | 20 | 101464 | 677.8 | 694 | 670 | 148.7 |
| C | 15 | 224 | 2139391 | 12703.06 | 612 | 608 | 168.4 |
| C | 1 | 241 | 1819052 | 10800.45 | 612 | 608 | 168.4 |
| C | 12 | 252 | 498399 | 2956.57 | 612 | 608 | 168.4 |
| D | 8 | 176 | 10372326 | 114449.76 | 303 | 289 | 90.6 |
| D | 3 | 12 | 422853 | 4662.76 | 303 | 289 | 90.6 |
| D | 2 | 120 | 74808 | 822.27 | 303 | 289 | 90.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
