| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_004T05_9000006502_53616cztM0_level2.fits | modeM0/AS1A14_004T05_9000006502_53616cztM0_level2_quad_clean.evt |
| Size (bytes) | 929,505,600 | 79,721,280 |
| Size | 886.4 MB | 76.0 MB |
| Events in quadrant A | 11,628,956 | 310,722 |
| Events in quadrant B | 8,786,938 | 535,810 |
| Events in quadrant C | 6,585,465 | 560,718 |
| Events in quadrant D | 6,899,833 | 549,293 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 39027 | 8 |
| B | 0 | 30605 | 2 |
| C | 0 | 24052 | 2 |
| D | 0 | 25025 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6552 | 3720 | 56.776557% |
| B | 6552 | 2122 | 32.387057% |
| C | 6552 | 1010 | 15.415140% |
| D | 6552 | 920 | 14.041514% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7701 | 6559 | 3558 | 3558 | 46.20% | 54.25% |  |
| B | 7702 | 6562 | 1808 | 1808 | 23.47% | 27.55% |  |
| C | 7702 | 6559 | 833 | 833 | 10.82% | 12.70% |  |
| D | 7701 | 6561 | 821 | 821 | 10.66% | 12.51% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 95 | 6261713 | 50155.44 | 504 | 493 | 124.8 |
| A | 3 | 78 | 2770376 | 22188.12 | 504 | 493 | 124.8 |
| A | 15 | 174 | 182844 | 1460.72 | 504 | 493 | 124.8 |
| B | 10 | 254 | 5023705 | 33610.6 | 694 | 669 | 149.4 |
| B | 15 | 20 | 324960 | 2169.93 | 694 | 669 | 149.4 |
| B | 5 | 172 | 226662 | 1512.19 | 694 | 669 | 149.4 |
| C | 15 | 224 | 2966274 | 15810.15 | 687 | 680 | 187.6 |
| C | 1 | 241 | 325050 | 1729.28 | 687 | 680 | 187.6 |
| C | 13 | 3 | 177233 | 941.24 | 687 | 680 | 187.6 |
| D | 8 | 176 | 2808585 | 14062.4 | 704 | 671 | 199.7 |
| D | 10 | 172 | 386334 | 1931.45 | 704 | 671 | 199.7 |
| D | 3 | 12 | 192628 | 961.35 | 704 | 671 | 199.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
