| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_022T05_9000006504_53640cztM0_level2.fits | modeM0/AS1A14_022T05_9000006504_53640cztM0_level2_quad_clean.evt |
| Size (bytes) | 794,727,360 | 90,895,680 |
| Size | 757.9 MB | 86.7 MB |
| Events in quadrant A | 5,737,854 | 611,470 |
| Events in quadrant B | 7,325,002 | 641,346 |
| Events in quadrant C | 9,675,663 | 452,717 |
| Events in quadrant D | 6,144,505 | 563,930 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21827 | 2 |
| B | 0 | 26627 | 2 |
| C | 0 | 33414 | 2 |
| D | 0 | 23221 | 3 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6927 | 634 | 9.152591% |
| B | 6927 | 913 | 13.180309% |
| C | 6927 | 2165 | 31.254511% |
| D | 6926 | 500 | 7.219174% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7870 | 6952 | 546 | 546 | 6.94% | 7.85% |  |
| B | 7870 | 6953 | 549 | 549 | 6.98% | 7.90% |  |
| C | 7870 | 6942 | 1955 | 1955 | 24.84% | 28.16% |  |
| D | 7869 | 6952 | 500 | 500 | 6.35% | 7.19% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 78 | 1633967 | 9137.15 | 721 | 705 | 178.7 |
| A | 15 | 174 | 420025 | 2345.85 | 721 | 705 | 178.7 |
| A | 0 | 8 | 398519 | 2225.54 | 721 | 705 | 178.7 |
| B | 4 | 206 | 1925627 | 12710.36 | 709 | 686 | 151.4 |
| B | 7 | 0 | 1177405 | 7769.86 | 709 | 686 | 151.4 |
| B | 15 | 20 | 588094 | 3878.65 | 709 | 686 | 151.4 |
| C | 1 | 241 | 4575636 | 27463.44 | 594 | 589 | 166.6 |
| C | 15 | 224 | 1574083 | 9445.49 | 594 | 589 | 166.6 |
| C | 6 | 13 | 253729 | 1519.57 | 594 | 589 | 166.6 |
| D | 8 | 176 | 1692823 | 8472.42 | 697 | 669 | 199.7 |
| D | 10 | 172 | 579760 | 2899.44 | 697 | 669 | 199.7 |
| D | 6 | 29 | 247006 | 1233.38 | 697 | 669 | 199.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
