| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_022T05_9000006504_53677cztM0_level2.fits | modeM0/AS1A14_022T05_9000006504_53677cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,117,321,920 | 79,741,440 |
| Size | 1.0 GB | 76.0 MB |
| Events in quadrant A | 14,463,614 | 301,755 |
| Events in quadrant B | 4,274,535 | 730,635 |
| Events in quadrant C | 11,766,721 | 425,142 |
| Events in quadrant D | 10,282,776 | 440,750 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 150 | 0 |
| B | 0 | 150 | 0 |
| C | 0 | 150 | 0 |
| D | 0 | 150 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 48069 | 2 |
| B | 0 | 17845 | 2 |
| C | 0 | 40067 | 2 |
| D | 0 | 35687 | 8 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7409 | 4564 | 61.600756% |
| B | 7409 | 372 | 5.020921% |
| C | 7410 | 3225 | 43.522267% |
| D | 7409 | 2521 | 34.026184% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7638 | 7408 | 4060 | 4060 | 53.16% | 54.81% |  |
| B | 7639 | 7411 | 90 | 90 | 1.18% | 1.21% |  |
| C | 7639 | 7409 | 2608 | 2608 | 34.14% | 35.20% |  |
| D | 7639 | 7410 | 2215 | 2215 | 29.00% | 29.89% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 63 | 10817339 | 69705.64 | 620 | 604 | 155.2 |
| A | 15 | 174 | 504801 | 3249.17 | 620 | 604 | 155.2 |
| A | 3 | 78 | 267339 | 1718.9 | 620 | 604 | 155.2 |
| B | 5 | 185 | 240990 | 1359.53 | 814 | 786 | 176.7 |
| B | 0 | 171 | 203934 | 1149.8 | 814 | 786 | 176.7 |
| B | 4 | 216 | 128423 | 722.41 | 814 | 786 | 176.7 |
| C | 15 | 224 | 7246017 | 40172.74 | 649 | 644 | 180.4 |
| C | 1 | 241 | 492098 | 2724.92 | 649 | 644 | 180.4 |
| C | 13 | 3 | 361973 | 2003.43 | 649 | 644 | 180.4 |
| D | 8 | 176 | 5107444 | 27388.41 | 648 | 619 | 186.5 |
| D | 12 | 34 | 1223208 | 6556.87 | 648 | 619 | 186.5 |
| D | 7 | 70 | 344492 | 1844.23 | 648 | 619 | 186.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
