| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_022T04_9000006506_53735cztM0_level2.fits | modeM0/AS1A14_022T04_9000006506_53735cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,084,023,360 | 67,680,000 |
| Size | 1.0 GB | 64.5 MB |
| Events in quadrant A | 17,135,932 | 4,936 |
| Events in quadrant B | 3,269,455 | 674,216 |
| Events in quadrant C | 8,958,596 | 494,620 |
| Events in quadrant D | 10,229,369 | 393,767 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 55701 | 1 |
| B | 0 | 14992 | 1 |
| C | 0 | 31475 | 1 |
| D | 0 | 35210 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6902 | 6867 | 99.492901% |
| B | 6902 | 268 | 3.882932% |
| C | 6902 | 1618 | 23.442480% |
| D | 6902 | 2490 | 36.076500% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7116 | 6901 | 6164 | 6164 | 86.62% | 89.32% |  |
| B | 7117 | 6903 | 32 | 32 | 0.45% | 0.46% |  |
| C | 7116 | 6902 | 1354 | 1354 | 19.03% | 19.62% |  |
| D | 7117 | 6902 | 2079 | 2079 | 29.21% | 30.12% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 63 | 15229741 | 296399.17 | 200 | 194 | 51.4 |
| A | 3 | 78 | 868454 | 16898.17 | 200 | 194 | 51.4 |
| A | 8 | 245 | 166195 | 3230.73 | 200 | 194 | 51.4 |
| B | 0 | 213 | 130571 | 819.26 | 733 | 705 | 158.5 |
| B | 10 | 247 | 91391 | 572.09 | 733 | 705 | 158.5 |
| B | 5 | 185 | 30057 | 185.17 | 733 | 705 | 158.5 |
| C | 15 | 224 | 2986855 | 17277.77 | 631 | 626 | 172.8 |
| C | 3 | 242 | 1508927 | 8726.75 | 631 | 626 | 172.8 |
| C | 1 | 241 | 1077908 | 6232.95 | 631 | 626 | 172.8 |
| D | 8 | 176 | 3948088 | 23706.44 | 582 | 558 | 166.5 |
| D | 1 | 241 | 1314149 | 7888.62 | 582 | 558 | 166.5 |
| D | 6 | 239 | 1256816 | 7544.31 | 582 | 558 | 166.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
