| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_022T04_9000006506_53775cztM0_level2.fits | modeM0/AS1A14_022T04_9000006506_53775cztM0_level2_quad_clean.evt |
| Size (bytes) | 779,414,400 | 76,265,280 |
| Size | 743.3 MB | 72.7 MB |
| Events in quadrant A | 15,911,694 | 61,082 |
| Events in quadrant B | 3,402,581 | 666,656 |
| Events in quadrant C | 5,490,256 | 582,606 |
| Events in quadrant D | 3,553,776 | 555,701 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 51682 | 1 |
| B | 0 | 14516 | 1 |
| C | 0 | 20711 | 1 |
| D | 0 | 15017 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6348 | 5876 | 92.564587% |
| B | 6348 | 202 | 3.182105% |
| C | 6349 | 412 | 6.489211% |
| D | 6349 | 187 | 2.945346% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7488 | 6348 | 5818 | 5818 | 77.70% | 91.65% |  |
| B | 7487 | 6347 | 48 | 48 | 0.64% | 0.76% |  |
| C | 7489 | 6349 | 355 | 355 | 4.74% | 5.59% |  |
| D | 7489 | 6349 | 141 | 141 | 1.88% | 2.22% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 63 | 14514693 | 175751.06 | 331 | 323 | 82.6 |
| A | 4 | 249 | 29912 | 358.29 | 331 | 323 | 82.6 |
| A | 4 | 3 | 22254 | 265.56 | 331 | 323 | 82.6 |
| B | 0 | 213 | 224954 | 1510.19 | 690 | 666 | 148.5 |
| B | 6 | 255 | 124093 | 831.07 | 690 | 666 | 148.5 |
| B | 5 | 250 | 61304 | 408.29 | 690 | 666 | 148.5 |
| C | 15 | 224 | 1690764 | 9179.81 | 665 | 660 | 184.1 |
| C | 7 | 64 | 499087 | 2707.21 | 665 | 660 | 184.1 |
| C | 9 | 38 | 282180 | 1529.08 | 665 | 660 | 184.1 |
| D | 8 | 176 | 228960 | 1204.55 | 667 | 638 | 189.5 |
| D | 2 | 120 | 183828 | 966.45 | 667 | 638 | 189.5 |
| D | 2 | 172 | 138105 | 725.23 | 667 | 638 | 189.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
