| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_022T04_9000006506_53822cztM0_level2.fits | modeM0/AS1A14_022T04_9000006506_53822cztM0_level2_quad_clean.evt |
| Size (bytes) | 789,753,600 | 90,313,920 |
| Size | 753.2 MB | 86.1 MB |
| Events in quadrant A | 3,488,290 | 667,134 |
| Events in quadrant B | 4,537,995 | 701,986 |
| Events in quadrant C | 9,630,764 | 454,764 |
| Events in quadrant D | 11,013,208 | 403,949 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15853 | 1 |
| B | 0 | 18689 | 1 |
| C | 0 | 33655 | 1 |
| D | 0 | 37787 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7274 | 267 | 3.670608% |
| B | 7274 | 400 | 5.499038% |
| C | 7275 | 2394 | 32.907216% |
| D | 7275 | 2843 | 39.079038% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7574 | 7276 | 49 | 49 | 0.65% | 0.67% |  |
| B | 7574 | 7276 | 85 | 85 | 1.12% | 1.17% |  |
| C | 7575 | 7276 | 2107 | 2107 | 27.82% | 28.96% |  |
| D | 7575 | 7277 | 2487 | 2487 | 32.83% | 34.18% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 8 | 240002 | 1247.32 | 782 | 762 | 191.8 |
| A | 8 | 245 | 82124 | 424.2 | 782 | 762 | 191.8 |
| A | 8 | 249 | 31686 | 161.23 | 782 | 762 | 191.8 |
| B | 10 | 254 | 666458 | 4056.32 | 766 | 737 | 164.1 |
| B | 5 | 250 | 288853 | 1755.52 | 766 | 737 | 164.1 |
| B | 5 | 185 | 213518 | 1296.5 | 766 | 737 | 164.1 |
| C | 1 | 241 | 5213742 | 29787.1 | 635 | 628 | 175.0 |
| C | 15 | 224 | 1550720 | 8857.04 | 635 | 628 | 175.0 |
| C | 7 | 64 | 115326 | 655.37 | 635 | 628 | 175.0 |
| D | 8 | 176 | 6510612 | 37269.19 | 617 | 589 | 174.7 |
| D | 2 | 172 | 847304 | 4847.35 | 617 | 589 | 174.7 |
| D | 15 | 93 | 525466 | 3004.86 | 617 | 589 | 174.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
