| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_041T01_9000006510_54010cztM0_level2.fits | modeM0/AS1A14_041T01_9000006510_54010cztM0_level2_quad_clean.evt |
| Size (bytes) | 571,662,720 | 85,904,640 |
| Size | 545.2 MB | 81.9 MB |
| Events in quadrant A | 3,699,423 | 584,016 |
| Events in quadrant B | 3,399,157 | 668,401 |
| Events in quadrant C | 3,848,414 | 574,886 |
| Events in quadrant D | 9,713,733 | 324,955 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16035 | 1 |
| B | 0 | 14841 | 1 |
| C | 0 | 16188 | 1 |
| D | 0 | 33458 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6433 | 353 | 5.487331% |
| B | 6434 | 85 | 1.321107% |
| C | 6434 | 214 | 3.326080% |
| D | 6434 | 2790 | 43.363382% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7403 | 6434 | 312 | 312 | 4.21% | 4.85% |  |
| B | 7404 | 6435 | 42 | 42 | 0.57% | 0.65% |  |
| C | 7404 | 6435 | 152 | 152 | 2.05% | 2.36% |  |
| D | 7404 | 6435 | 2343 | 2343 | 31.65% | 36.41% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 926961 | 5811.58 | 644 | 627 | 159.4 |
| A | 0 | 8 | 110042 | 686.44 | 644 | 627 | 159.4 |
| A | 8 | 249 | 69718 | 433.46 | 644 | 627 | 159.4 |
| B | 0 | 213 | 327334 | 2321.75 | 663 | 640 | 140.7 |
| B | 4 | 81 | 283966 | 2013.54 | 663 | 640 | 140.7 |
| B | 7 | 252 | 47408 | 332.37 | 663 | 640 | 140.7 |
| C | 14 | 80 | 507855 | 2837.2 | 650 | 643 | 178.8 |
| C | 4 | 5 | 275634 | 1538.22 | 650 | 643 | 178.8 |
| C | 12 | 250 | 247323 | 1379.85 | 650 | 643 | 178.8 |
| D | 8 | 176 | 7207171 | 54804.63 | 458 | 437 | 131.5 |
| D | 10 | 172 | 253892 | 1927.43 | 458 | 437 | 131.5 |
| D | 14 | 20 | 118927 | 901.07 | 458 | 437 | 131.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
