| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_012T01_9000006512_54108cztM0_level2.fits | modeM0/AS1A14_012T01_9000006512_54108cztM0_level2_quad_clean.evt |
| Size (bytes) | 354,124,800 | 93,499,200 |
| Size | 337.7 MB | 89.2 MB |
| Events in quadrant A | 2,904,534 | 612,736 |
| Events in quadrant B | 3,297,533 | 657,589 |
| Events in quadrant C | 3,039,373 | 581,146 |
| Events in quadrant D | 3,381,318 | 544,698 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13244 | 1 |
| B | 0 | 14026 | 1 |
| C | 0 | 13712 | 1 |
| D | 0 | 14423 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6236 | 80 | 1.282874% |
| B | 6236 | 119 | 1.908275% |
| C | 6236 | 104 | 1.667736% |
| D | 6236 | 94 | 1.507377% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7326 | 6237 | 19 | 19 | 0.26% | 0.30% |  |
| B | 7326 | 6237 | 58 | 58 | 0.79% | 0.93% |  |
| C | 7326 | 6237 | 49 | 49 | 0.67% | 0.79% |  |
| D | 7326 | 6237 | 35 | 35 | 0.48% | 0.56% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 248 | 87768 | 530.78 | 664 | 648 | 164.1 |
| A | 15 | 174 | 72050 | 435.02 | 664 | 648 | 164.1 |
| A | 0 | 8 | 29180 | 173.83 | 664 | 648 | 164.1 |
| B | 0 | 213 | 144859 | 1038.32 | 654 | 629 | 138.9 |
| B | 10 | 245 | 117707 | 842.85 | 654 | 629 | 138.9 |
| B | 7 | 252 | 104006 | 744.22 | 654 | 629 | 138.9 |
| C | 13 | 3 | 357488 | 2020.58 | 643 | 636 | 176.6 |
| C | 9 | 53 | 45263 | 252.69 | 643 | 636 | 176.6 |
| C | 12 | 250 | 26142 | 144.42 | 643 | 636 | 176.6 |
| D | 2 | 165 | 263124 | 1442.67 | 643 | 613 | 182.0 |
| D | 8 | 176 | 140416 | 768.31 | 643 | 613 | 182.0 |
| D | 3 | 12 | 117432 | 641.99 | 643 | 613 | 182.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
