| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_012T01_9000006512_54153cztM0_level2.fits | modeM0/AS1A14_012T01_9000006512_54153cztM0_level2_quad_clean.evt |
| Size (bytes) | 424,267,200 | 95,034,240 |
| Size | 404.6 MB | 90.6 MB |
| Events in quadrant A | 4,095,989 | 619,164 |
| Events in quadrant B | 3,539,049 | 672,008 |
| Events in quadrant C | 2,889,044 | 600,534 |
| Events in quadrant D | 4,684,385 | 540,173 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16612 | 1 |
| B | 0 | 15003 | 1 |
| C | 0 | 13200 | 1 |
| D | 0 | 18349 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6384 | 279 | 4.370301% |
| B | 6384 | 167 | 2.615915% |
| C | 6384 | 34 | 0.532581% |
| D | 6384 | 352 | 5.513784% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7499 | 6385 | 177 | 177 | 2.36% | 2.77% |  |
| B | 7499 | 6385 | 81 | 81 | 1.08% | 1.27% |  |
| C | 7499 | 6385 | 12 | 12 | 0.16% | 0.19% |  |
| D | 7499 | 6385 | 309 | 309 | 4.12% | 4.84% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 249 | 480980 | 2885.54 | 671 | 655 | 166.5 |
| A | 7 | 29 | 364447 | 2185.47 | 671 | 655 | 166.5 |
| A | 15 | 174 | 346403 | 2077.07 | 671 | 655 | 166.5 |
| B | 4 | 171 | 192369 | 1346.69 | 668 | 644 | 142.4 |
| B | 10 | 245 | 160457 | 1122.54 | 668 | 644 | 142.4 |
| B | 5 | 236 | 150596 | 1053.27 | 668 | 644 | 142.4 |
| C | 3 | 242 | 123203 | 664.82 | 663 | 655 | 184.3 |
| C | 12 | 252 | 34687 | 184.62 | 663 | 655 | 184.3 |
| C | 15 | 157 | 33417 | 177.73 | 663 | 655 | 184.3 |
| D | 8 | 176 | 1741770 | 9445.1 | 649 | 622 | 184.3 |
| D | 3 | 12 | 90098 | 485.37 | 649 | 622 | 184.3 |
| D | 2 | 62 | 47476 | 254.17 | 649 | 622 | 184.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
