| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C09_004T08_9000006514_54197cztM0_level2.fits | modeM0/AS1C09_004T08_9000006514_54197cztM0_level2_quad_clean.evt |
| Size (bytes) | 507,695,040 | 86,126,400 |
| Size | 484.2 MB | 82.1 MB |
| Events in quadrant A | 4,134,047 | 573,127 |
| Events in quadrant B | 3,902,157 | 622,610 |
| Events in quadrant C | 3,526,589 | 527,805 |
| Events in quadrant D | 6,728,254 | 433,140 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16429 | 1 |
| B | 0 | 15919 | 1 |
| C | 0 | 15164 | 1 |
| D | 0 | 24560 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6463 | 210 | 3.249265% |
| B | 6463 | 147 | 2.274486% |
| C | 6463 | 166 | 2.568467% |
| D | 6463 | 1314 | 20.331116% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7863 | 6739 | 141 | 141 | 1.79% | 2.09% |  |
| B | 7863 | 6739 | 80 | 80 | 1.02% | 1.19% |  |
| C | 7863 | 6739 | 142 | 142 | 1.81% | 2.11% |  |
| D | 7863 | 6738 | 1271 | 1271 | 16.16% | 18.86% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 11 | 3 | 343181 | 1988.22 | 693 | 676 | 172.3 |
| A | 7 | 29 | 335475 | 1943.48 | 693 | 676 | 172.3 |
| A | 15 | 174 | 272820 | 1579.78 | 693 | 676 | 172.3 |
| B | 15 | 20 | 326327 | 2222.44 | 687 | 662 | 146.5 |
| B | 4 | 171 | 230076 | 1565.6 | 687 | 662 | 146.5 |
| B | 5 | 185 | 172282 | 1171.19 | 687 | 662 | 146.5 |
| C | 15 | 215 | 305012 | 1656.02 | 664 | 655 | 183.8 |
| C | 12 | 2 | 216627 | 1175.11 | 664 | 655 | 183.8 |
| C | 15 | 189 | 87875 | 474.57 | 664 | 655 | 183.8 |
| D | 8 | 176 | 3758726 | 21882.9 | 598 | 569 | 171.7 |
| D | 3 | 12 | 239962 | 1393.93 | 598 | 569 | 171.7 |
| D | 2 | 172 | 142024 | 823.66 | 598 | 569 | 171.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
