| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C09_004T08_9000006514_54213cztM0_level2.fits | modeM0/AS1C09_004T08_9000006514_54213cztM0_level2_quad_clean.evt |
| Size (bytes) | 476,812,800 | 97,767,360 |
| Size | 454.7 MB | 93.2 MB |
| Events in quadrant A | 3,272,423 | 667,982 |
| Events in quadrant B | 4,062,225 | 703,946 |
| Events in quadrant C | 3,155,708 | 618,152 |
| Events in quadrant D | 6,625,570 | 491,915 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14787 | 1 |
| B | 0 | 16957 | 1 |
| C | 0 | 14692 | 1 |
| D | 0 | 24422 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6862 | 125 | 1.821626% |
| B | 6863 | 301 | 4.385837% |
| C | 6863 | 107 | 1.559085% |
| D | 6862 | 1267 | 18.464005% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7727 | 6862 | 45 | 45 | 0.58% | 0.66% |  |
| B | 7728 | 6863 | 221 | 221 | 2.86% | 3.22% |  |
| C | 7728 | 6863 | 55 | 55 | 0.71% | 0.80% |  |
| D | 7726 | 6861 | 1218 | 1218 | 15.76% | 17.75% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 7 | 29 | 168141 | 929.35 | 731 | 712 | 180.2 |
| A | 15 | 174 | 88860 | 489.29 | 731 | 712 | 180.2 |
| A | 4 | 3 | 53286 | 291.82 | 731 | 712 | 180.2 |
| B | 4 | 171 | 503070 | 3323.15 | 712 | 687 | 151.2 |
| B | 4 | 67 | 274898 | 1813.84 | 712 | 687 | 151.2 |
| B | 5 | 236 | 242781 | 1601.4 | 712 | 687 | 151.2 |
| C | 12 | 252 | 235069 | 1221.5 | 705 | 696 | 191.9 |
| C | 12 | 241 | 44541 | 228.51 | 705 | 696 | 191.9 |
| C | 14 | 254 | 32444 | 165.46 | 705 | 696 | 191.9 |
| D | 8 | 176 | 2930691 | 16271.23 | 638 | 609 | 180.1 |
| D | 3 | 12 | 522147 | 2896.19 | 638 | 609 | 180.1 |
| D | 2 | 153 | 155276 | 858.89 | 638 | 609 | 180.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
