| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_126T15_9000006516_54282cztM0_level2.fits | modeM0/AS1A14_126T15_9000006516_54282cztM0_level2_quad_clean.evt |
| Size (bytes) | 380,442,240 | 93,945,600 |
| Size | 362.8 MB | 89.6 MB |
| Events in quadrant A | 3,020,877 | 618,313 |
| Events in quadrant B | 3,215,450 | 666,757 |
| Events in quadrant C | 2,692,528 | 591,374 |
| Events in quadrant D | 4,658,864 | 524,557 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13661 | 1 |
| B | 0 | 14161 | 1 |
| C | 0 | 13120 | 5 |
| D | 0 | 18339 | 5 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6359 | 67 | 1.053625% |
| B | 6360 | 49 | 0.770440% |
| C | 6357 | 11 | 0.173038% |
| D | 6358 | 376 | 5.913809% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7504 | 6360 | 72 | 72 | 0.96% | 1.13% |  |
| B | 7505 | 6360 | 11 | 11 | 0.15% | 0.17% |  |
| C | 7505 | 6360 | 5 | 5 | 0.07% | 0.08% |  |
| D | 7505 | 6360 | 389 | 389 | 5.18% | 6.12% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 201192 | 1215.4 | 666 | 649 | 165.0 |
| A | 3 | 110 | 101789 | 612.96 | 666 | 649 | 165.0 |
| A | 4 | 3 | 41548 | 247.87 | 666 | 649 | 165.0 |
| B | 7 | 0 | 331110 | 2321.54 | 661 | 635 | 142.4 |
| B | 5 | 185 | 141909 | 992.43 | 661 | 635 | 142.4 |
| B | 0 | 213 | 29425 | 202.25 | 661 | 635 | 142.4 |
| C | 14 | 254 | 69573 | 393.09 | 639 | 633 | 175.4 |
| C | 12 | 2 | 44388 | 249.49 | 639 | 633 | 175.4 |
| C | 12 | 249 | 16657 | 91.37 | 639 | 633 | 175.4 |
| D | 6 | 239 | 854131 | 4818.89 | 618 | 589 | 177.1 |
| D | 2 | 153 | 324370 | 1827.99 | 618 | 589 | 177.1 |
| D | 8 | 176 | 272257 | 1533.77 | 618 | 589 | 177.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
