| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_126T15_9000006516_54327cztM0_level2.fits | modeM0/AS1A14_126T15_9000006516_54327cztM0_level2_quad_clean.evt |
| Size (bytes) | 644,077,440 | 79,493,760 |
| Size | 614.2 MB | 75.8 MB |
| Events in quadrant A | 2,686,270 | 593,613 |
| Events in quadrant B | 3,036,865 | 614,196 |
| Events in quadrant C | 7,703,546 | 491,871 |
| Events in quadrant D | 9,955,950 | 293,758 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 120 | 0 |
| B | 0 | 120 | 0 |
| C | 0 | 120 | 0 |
| D | 0 | 120 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12233 | 1 |
| B | 0 | 13446 | 1 |
| C | 0 | 27103 | 1 |
| D | 0 | 33705 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5918 | 19 | 0.321054% |
| B | 5919 | 205 | 3.463423% |
| C | 5919 | 985 | 16.641325% |
| D | 5919 | 2846 | 48.082446% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7098 | 5919 | 5 | 5 | 0.07% | 0.08% |  |
| B | 7099 | 5920 | 125 | 125 | 1.76% | 2.11% |  |
| C | 7099 | 5920 | 1000 | 1000 | 14.09% | 16.89% |  |
| D | 7099 | 5920 | 2679 | 2679 | 37.74% | 45.25% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 11 | 3 | 67555 | 428.31 | 629 | 614 | 156.3 |
| A | 15 | 174 | 63427 | 401.9 | 629 | 614 | 156.3 |
| A | 8 | 246 | 29459 | 184.56 | 629 | 614 | 156.3 |
| B | 2 | 249 | 217606 | 1663.64 | 612 | 592 | 130.4 |
| B | 5 | 172 | 209110 | 1598.51 | 612 | 592 | 130.4 |
| B | 0 | 213 | 58018 | 440.23 | 612 | 592 | 130.4 |
| C | 1 | 16 | 3658556 | 23511.01 | 567 | 562 | 155.6 |
| C | 1 | 241 | 797267 | 5120.66 | 567 | 562 | 155.6 |
| C | 13 | 3 | 541236 | 3475.07 | 567 | 562 | 155.6 |
| D | 8 | 176 | 7514960 | 63872.36 | 415 | 397 | 117.6 |
| D | 15 | 108 | 289231 | 2455.03 | 415 | 397 | 117.6 |
| D | 6 | 239 | 209173 | 1774.56 | 415 | 397 | 117.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
