| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_126T19_9000006518_54374cztM0_level2.fits | modeM0/AS1A14_126T19_9000006518_54374cztM0_level2_quad_clean.evt |
| Size (bytes) | 539,159,040 | 102,176,640 |
| Size | 514.2 MB | 97.4 MB |
| Events in quadrant A | 3,656,382 | 672,600 |
| Events in quadrant B | 5,106,408 | 707,424 |
| Events in quadrant C | 5,897,569 | 590,975 |
| Events in quadrant D | 4,723,844 | 608,509 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16347 | 3 |
| B | 0 | 20264 | 3 |
| C | 0 | 22848 | 6 |
| D | 0 | 19234 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7382 | 313 | 4.240043% |
| B | 7383 | 575 | 7.788162% |
| C | 7382 | 937 | 12.693037% |
| D | 7383 | 247 | 3.345523% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7737 | 7384 | 18 | 18 | 0.23% | 0.24% |  |
| B | 7738 | 7385 | 281 | 281 | 3.63% | 3.81% |  |
| C | 7738 | 7385 | 765 | 765 | 9.89% | 10.36% |  |
| D | 7738 | 7385 | 114 | 114 | 1.47% | 1.54% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 115 | 280181 | 1419.33 | 797 | 776 | 196.9 |
| A | 0 | 8 | 155727 | 787.13 | 797 | 776 | 196.9 |
| A | 4 | 3 | 26675 | 131.56 | 797 | 776 | 196.9 |
| B | 10 | 14 | 1305030 | 7870.08 | 773 | 743 | 165.7 |
| B | 7 | 0 | 467100 | 2814.0 | 773 | 743 | 165.7 |
| B | 0 | 171 | 46179 | 274.16 | 773 | 743 | 165.7 |
| C | 1 | 241 | 1822351 | 9072.0 | 735 | 728 | 200.8 |
| C | 13 | 3 | 586703 | 2918.26 | 735 | 728 | 200.8 |
| C | 1 | 29 | 147113 | 729.02 | 735 | 728 | 200.8 |
| D | 8 | 176 | 772476 | 3619.27 | 766 | 731 | 213.2 |
| D | 3 | 12 | 444699 | 2082.09 | 766 | 731 | 213.2 |
| D | 12 | 3 | 129300 | 602.95 | 766 | 731 | 213.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
