| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_126T19_9000006518_54416cztM0_level2.fits | modeM0/AS1A14_126T19_9000006518_54416cztM0_level2_quad_clean.evt |
| Size (bytes) | 594,590,400 | 78,816,960 |
| Size | 567.0 MB | 75.2 MB |
| Events in quadrant A | 2,684,510 | 581,151 |
| Events in quadrant B | 2,825,641 | 621,140 |
| Events in quadrant C | 9,118,566 | 313,991 |
| Events in quadrant D | 6,905,323 | 442,861 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12785 | 1 |
| B | 0 | 12986 | 1 |
| C | 0 | 31587 | 1 |
| D | 0 | 24823 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6121 | 40 | 0.653488% |
| B | 6121 | 71 | 1.159941% |
| C | 6122 | 2834 | 46.292061% |
| D | 6122 | 1013 | 16.546880% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7186 | 6122 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7186 | 6121 | 14 | 14 | 0.19% | 0.23% |  |
| C | 7187 | 6123 | 2905 | 2905 | 40.42% | 47.44% |  |
| D | 7187 | 6123 | 1082 | 1082 | 15.05% | 17.67% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 7 | 206 | 130343 | 812.85 | 644 | 628 | 159.6 |
| A | 4 | 3 | 25424 | 155.38 | 644 | 628 | 159.6 |
| A | 13 | 254 | 12101 | 71.89 | 644 | 628 | 159.6 |
| B | 5 | 185 | 87826 | 635.4 | 632 | 608 | 137.3 |
| B | 7 | 0 | 63068 | 455.03 | 632 | 608 | 137.3 |
| B | 0 | 197 | 58329 | 420.51 | 632 | 608 | 137.3 |
| C | 4 | 5 | 6914153 | 49631.33 | 509 | 505 | 139.3 |
| C | 14 | 254 | 68267 | 486.45 | 509 | 505 | 139.3 |
| C | 13 | 3 | 54961 | 390.93 | 509 | 505 | 139.3 |
| D | 8 | 176 | 1525607 | 9210.98 | 576 | 549 | 165.6 |
| D | 7 | 70 | 1007735 | 6083.16 | 576 | 549 | 165.6 |
| D | 3 | 12 | 970971 | 5861.11 | 576 | 549 | 165.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
