| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_126T19_9000006518_54423cztM0_level2.fits | modeM0/AS1A14_126T19_9000006518_54423cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,767,772,800 | 245,669,760 |
| Size | 1.6 GB | 234.3 MB |
| Events in quadrant A | 9,934,768 | 1,767,159 |
| Events in quadrant B | 9,685,908 | 1,874,475 |
| Events in quadrant C | 12,003,082 | 1,606,151 |
| Events in quadrant D | 32,319,995 | 859,768 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 392 | 0 |
| B | 0 | 392 | 0 |
| C | 0 | 392 | 0 |
| D | 0 | 392 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 43064 | 3 |
| B | 0 | 42905 | 3 |
| C | 0 | 50216 | 3 |
| D | 0 | 109380 | 8 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 19304 | 402 | 2.082470% |
| B | 19304 | 444 | 2.300041% |
| C | 19305 | 1265 | 6.552707% |
| D | 19304 | 8872 | 45.959387% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 20408 | 19306 | 186 | 186 | 0.91% | 0.96% |  |
| B | 20408 | 19305 | 100 | 100 | 0.49% | 0.52% |  |
| C | 20409 | 19306 | 1075 | 1075 | 5.27% | 5.57% |  |
| D | 20408 | 19305 | 8707 | 8707 | 42.66% | 45.10% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 253 | 583326 | 1151.1 | 2054 | 1996 | 505.0 |
| A | 7 | 206 | 540331 | 1065.96 | 2054 | 1996 | 505.0 |
| A | 11 | 3 | 206187 | 404.32 | 2054 | 1996 | 505.0 |
| B | 0 | 213 | 689149 | 1590.01 | 2028 | 1953 | 432.2 |
| B | 5 | 185 | 427379 | 984.33 | 2028 | 1953 | 432.2 |
| B | 10 | 247 | 230970 | 529.89 | 2028 | 1953 | 432.2 |
| C | 1 | 241 | 2144707 | 4080.97 | 1950 | 1930 | 525.1 |
| C | 15 | 147 | 653918 | 1241.73 | 1950 | 1930 | 525.1 |
| C | 4 | 5 | 412889 | 782.68 | 1950 | 1930 | 525.1 |
| D | 7 | 70 | 11302856 | 25178.18 | 1562 | 1490 | 448.9 |
| D | 8 | 176 | 10316283 | 22980.21 | 1562 | 1490 | 448.9 |
| D | 12 | 3 | 1619353 | 3604.42 | 1562 | 1490 | 448.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
