| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_126T19_9000006518_54424cztM0_level2.fits | modeM0/AS1A14_126T19_9000006518_54424cztM0_level2_quad_clean.evt |
| Size (bytes) | 587,111,040 | 84,280,320 |
| Size | 559.9 MB | 80.4 MB |
| Events in quadrant A | 2,857,285 | 606,085 |
| Events in quadrant B | 3,204,813 | 640,288 |
| Events in quadrant C | 7,834,828 | 436,992 |
| Events in quadrant D | 7,331,547 | 415,765 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13270 | 1 |
| B | 0 | 14294 | 1 |
| C | 0 | 27964 | 1 |
| D | 0 | 26489 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6489 | 39 | 0.601017% |
| B | 6490 | 102 | 1.571649% |
| C | 6490 | 1818 | 28.012327% |
| D | 6489 | 1685 | 25.967021% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7284 | 6490 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7285 | 6491 | 27 | 27 | 0.37% | 0.42% |  |
| C | 7285 | 6491 | 1833 | 1833 | 25.16% | 28.24% |  |
| D | 7284 | 6490 | 1557 | 1557 | 21.38% | 23.99% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 11 | 3 | 92051 | 535.02 | 686 | 668 | 170.8 |
| A | 4 | 3 | 42965 | 247.64 | 686 | 668 | 170.8 |
| A | 0 | 8 | 28980 | 165.76 | 686 | 668 | 170.8 |
| B | 0 | 213 | 189304 | 1293.97 | 675 | 651 | 145.8 |
| B | 5 | 185 | 112237 | 765.37 | 675 | 651 | 145.8 |
| B | 10 | 247 | 102939 | 701.59 | 675 | 651 | 145.8 |
| C | 1 | 241 | 4456810 | 27912.18 | 580 | 573 | 159.7 |
| C | 4 | 5 | 803958 | 5032.1 | 580 | 573 | 159.7 |
| C | 5 | 10 | 107725 | 671.16 | 580 | 573 | 159.7 |
| D | 7 | 70 | 3751074 | 22556.31 | 582 | 556 | 166.3 |
| D | 8 | 176 | 262561 | 1575.75 | 582 | 556 | 166.3 |
| D | 6 | 239 | 232695 | 1396.13 | 582 | 556 | 166.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
