| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_126T19_9000006518_54427cztM0_level2.fits | modeM0/AS1A14_126T19_9000006518_54427cztM0_level2_quad_clean.evt |
| Size (bytes) | 463,392,000 | 90,403,200 |
| Size | 441.9 MB | 86.2 MB |
| Events in quadrant A | 2,808,876 | 621,035 |
| Events in quadrant B | 2,985,595 | 665,254 |
| Events in quadrant C | 5,246,728 | 531,979 |
| Events in quadrant D | 5,610,765 | 469,806 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13212 | 2 |
| B | 0 | 13674 | 2 |
| C | 0 | 20283 | 2 |
| D | 0 | 21311 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6442 | 14 | 0.217324% |
| B | 6442 | 30 | 0.465694% |
| C | 6441 | 793 | 12.311753% |
| D | 6441 | 993 | 15.416861% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7542 | 6443 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7542 | 6443 | 7 | 7 | 0.09% | 0.11% |  |
| C | 7541 | 6442 | 765 | 765 | 10.14% | 11.88% |  |
| D | 7541 | 6442 | 921 | 921 | 12.21% | 14.30% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 6 | 57615 | 339.46 | 678 | 662 | 167.8 |
| A | 4 | 3 | 28469 | 165.74 | 678 | 662 | 167.8 |
| A | 13 | 254 | 20424 | 117.79 | 678 | 662 | 167.8 |
| B | 10 | 247 | 84046 | 570.76 | 677 | 651 | 146.1 |
| B | 0 | 213 | 68270 | 462.79 | 677 | 651 | 146.1 |
| B | 5 | 185 | 62892 | 425.98 | 677 | 651 | 146.1 |
| C | 1 | 241 | 1620003 | 9390.15 | 625 | 620 | 172.5 |
| C | 13 | 3 | 440386 | 2550.03 | 625 | 620 | 172.5 |
| C | 4 | 5 | 300679 | 1739.92 | 625 | 620 | 172.5 |
| D | 7 | 70 | 1530812 | 8829.15 | 600 | 571 | 173.3 |
| D | 8 | 176 | 745312 | 4296.99 | 600 | 571 | 173.3 |
| D | 3 | 12 | 278027 | 1600.86 | 600 | 571 | 173.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
