| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_126T19_9000006518_54453cztM0_level2.fits | modeM0/AS1A14_126T19_9000006518_54453cztM0_level2_quad_clean.evt |
| Size (bytes) | 632,966,400 | 88,871,040 |
| Size | 603.6 MB | 84.8 MB |
| Events in quadrant A | 3,596,112 | 638,853 |
| Events in quadrant B | 3,394,218 | 685,315 |
| Events in quadrant C | 4,862,848 | 588,457 |
| Events in quadrant D | 11,038,187 | 295,068 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15738 | 2 |
| B | 0 | 15277 | 2 |
| C | 0 | 19318 | 2 |
| D | 0 | 37482 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6930 | 182 | 2.626263% |
| B | 6930 | 153 | 2.207792% |
| C | 6930 | 480 | 6.926407% |
| D | 6930 | 3485 | 50.288600% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7740 | 6931 | 110 | 110 | 1.42% | 1.59% |  |
| B | 7740 | 6931 | 61 | 61 | 0.79% | 0.88% |  |
| C | 7740 | 6931 | 345 | 345 | 4.46% | 4.98% |  |
| D | 7740 | 6931 | 3236 | 3236 | 41.81% | 46.69% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 8 | 375893 | 2064.94 | 736 | 717 | 181.7 |
| A | 8 | 9 | 127556 | 698.11 | 736 | 717 | 181.7 |
| A | 5 | 243 | 49196 | 266.82 | 736 | 717 | 181.7 |
| B | 2 | 249 | 195348 | 1233.86 | 731 | 705 | 157.8 |
| B | 10 | 247 | 105906 | 666.88 | 731 | 705 | 157.8 |
| B | 5 | 185 | 94184 | 592.57 | 731 | 705 | 157.8 |
| C | 13 | 3 | 1088765 | 5643.72 | 705 | 700 | 192.8 |
| C | 7 | 64 | 447527 | 2317.66 | 705 | 700 | 192.8 |
| C | 15 | 147 | 123002 | 634.37 | 705 | 700 | 192.8 |
| D | 7 | 70 | 6997311 | 51820.1 | 469 | 447 | 135.0 |
| D | 15 | 108 | 1083185 | 8018.96 | 469 | 447 | 135.0 |
| D | 8 | 176 | 379602 | 2808.09 | 469 | 447 | 135.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
