| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_103T01_9000006524_54775cztM0_level2.fits | modeM0/AS1A14_103T01_9000006524_54775cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,794,873,600 | 286,767,360 |
| Size | 1.7 GB | 273.5 MB |
| Events in quadrant A | 9,207,129 | 2,338,517 |
| Events in quadrant B | 31,140,997 | 1,152,929 |
| Events in quadrant C | 11,617,832 | 1,948,792 |
| Events in quadrant D | 13,033,755 | 1,958,479 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 388 | 2 |
| B | 0 | 387 | 0 |
| C | 0 | 386 | 0 |
| D | 0 | 386 | 2 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 43388 | 1279 |
| B | 0 | 106412 | 1203 |
| C | 0 | 49356 | 1113 |
| D | 0 | 53604 | 1256 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25 | 0 |
| B | 0 | 25 | 0 |
| C | 0 | 25 | 0 |
| D | 0 | 25 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 18631 | 431 | 2.313349% |
| B | 18639 | 9193 | 49.321316% |
| C | 18632 | 556 | 2.984113% |
| D | 18634 | 1111 | 5.962220% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 21665 | 18681 | 123 | 123 | 0.57% | 0.66% |  |
| B | 21702 | 18666 | 7964 | 7964 | 36.70% | 42.67% |  |
| C | 21667 | 18687 | 307 | 307 | 1.42% | 1.64% |  |
| D | 21655 | 18677 | 822 | 822 | 3.80% | 4.40% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 248 | 317859 | 513.39 | 2233 | 2182 | 614.9 |
| A | 0 | 8 | 108359 | 172.68 | 2233 | 2182 | 614.9 |
| A | 13 | 254 | 39572 | 60.81 | 2233 | 2182 | 614.9 |
| B | 2 | 249 | 23852021 | 70723.91 | 1515 | 1471 | 337.2 |
| B | 5 | 185 | 827487 | 2449.38 | 1515 | 1471 | 337.2 |
| B | 1 | 207 | 253023 | 745.93 | 1515 | 1471 | 337.2 |
| C | 9 | 38 | 1541928 | 2653.45 | 2025 | 2008 | 580.3 |
| C | 12 | 252 | 812786 | 1397.06 | 2025 | 2008 | 580.3 |
| C | 13 | 3 | 417122 | 715.29 | 2025 | 2008 | 580.3 |
| D | 11 | 129 | 1186724 | 1833.75 | 2122 | 2027 | 646.1 |
| D | 14 | 52 | 833348 | 1286.77 | 2122 | 2027 | 646.1 |
| D | 3 | 12 | 779061 | 1202.74 | 2122 | 2027 | 646.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
