| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_039T06_9000006526_54846cztM0_level2.fits | modeM0/AS1A14_039T06_9000006526_54846cztM0_level2_quad_clean.evt |
| Size (bytes) | 386,314,560 | 100,290,240 |
| Size | 368.4 MB | 95.6 MB |
| Events in quadrant A | 2,985,838 | 654,734 |
| Events in quadrant B | 3,157,922 | 696,257 |
| Events in quadrant C | 3,405,492 | 618,679 |
| Events in quadrant D | 4,208,222 | 581,867 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14432 | 2 |
| B | 0 | 14679 | 10 |
| C | 0 | 15608 | 2 |
| D | 0 | 17700 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6970 | 50 | 0.717360% |
| B | 6967 | 65 | 0.932970% |
| C | 6970 | 75 | 1.076040% |
| D | 6970 | 168 | 2.410330% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7855 | 6971 | 7 | 7 | 0.09% | 0.10% |  |
| B | 7855 | 6969 | 16 | 16 | 0.20% | 0.23% |  |
| C | 7855 | 6971 | 30 | 30 | 0.38% | 0.43% |  |
| D | 7855 | 6971 | 148 | 148 | 1.88% | 2.12% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 8 | 50841 | 273.58 | 726 | 710 | 183.2 |
| A | 13 | 248 | 46144 | 247.94 | 726 | 710 | 183.2 |
| A | 8 | 206 | 27466 | 146.01 | 726 | 710 | 183.2 |
| B | 7 | 0 | 101194 | 655.08 | 709 | 683 | 153.4 |
| B | 2 | 249 | 61299 | 395.06 | 709 | 683 | 153.4 |
| B | 10 | 247 | 41239 | 264.32 | 709 | 683 | 153.4 |
| C | 1 | 16 | 150298 | 772.33 | 697 | 692 | 193.7 |
| C | 9 | 38 | 113548 | 582.61 | 697 | 692 | 193.7 |
| C | 6 | 223 | 98747 | 506.2 | 697 | 692 | 193.7 |
| D | 8 | 160 | 595867 | 2995.19 | 693 | 663 | 198.7 |
| D | 3 | 12 | 454184 | 2282.21 | 693 | 663 | 198.7 |
| D | 2 | 252 | 130721 | 654.48 | 693 | 663 | 198.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
