| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_014T01_9000006528_54842cztM0_level2.fits | modeM0/AS1A14_014T01_9000006528_54842cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,828,382,400 | 192,366,720 |
| Size | 1.7 GB | 183.5 MB |
| Events in quadrant A | 10,779,141 | 1,356,980 |
| Events in quadrant B | 9,238,517 | 1,582,692 |
| Events in quadrant C | 8,132,978 | 1,471,163 |
| Events in quadrant D | 38,255,675 | 277,915 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 45633 | 1500 |
| B | 0 | 39955 | 595 |
| C | 0 | 37151 | 775 |
| D | 0 | 128585 | 3677 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 342 | 4 |
| B | 0 | 341 | 7 |
| C | 0 | 344 | 8 |
| D | 0 | 343 | 5 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23 | 0 |
| B | 0 | 23 | 0 |
| C | 0 | 23 | 0 |
| D | 0 | 23 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 16455 | 1531 | 9.304163% |
| B | 16513 | 952 | 5.765155% |
| C | 16507 | 351 | 2.126371% |
| D | 16352 | 13417 | 82.051125% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 19258 | 16538 | 927 | 927 | 4.81% | 5.61% |  |
| B | 19258 | 16608 | 576 | 576 | 2.99% | 3.47% |  |
| C | 19258 | 16600 | 90 | 90 | 0.47% | 0.54% |  |
| D | 19257 | 16381 | 13015 | 13015 | 67.59% | 79.45% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 32 | 3103526 | 7324.9 | 1728 | 1685 | 423.5 |
| A | 0 | 8 | 803807 | 1894.19 | 1728 | 1685 | 423.5 |
| A | 4 | 3 | 54449 | 124.6 | 1728 | 1685 | 423.5 |
| B | 4 | 81 | 1383105 | 3729.56 | 1733 | 1667 | 370.4 |
| B | 0 | 183 | 278646 | 747.78 | 1733 | 1667 | 370.4 |
| B | 5 | 236 | 158189 | 422.57 | 1733 | 1667 | 370.4 |
| C | 4 | 5 | 260705 | 534.46 | 1782 | 1767 | 484.5 |
| C | 6 | 223 | 213525 | 437.08 | 1782 | 1767 | 484.5 |
| C | 13 | 3 | 150884 | 307.78 | 1782 | 1767 | 484.5 |
| D | 15 | 94 | 33604946 | 150174.53 | 779 | 743 | 223.8 |
| D | 2 | 249 | 509169 | 2272.12 | 779 | 743 | 223.8 |
| D | 11 | 129 | 208833 | 929.94 | 779 | 743 | 223.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
