| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_014T01_9000006528_54911cztM0_level2.fits | modeM0/AS1A14_014T01_9000006528_54911cztM0_level2_quad_clean.evt |
| Size (bytes) | 512,530,560 | 97,597,440 |
| Size | 488.8 MB | 93.1 MB |
| Events in quadrant A | 3,974,867 | 640,723 |
| Events in quadrant B | 3,597,551 | 696,032 |
| Events in quadrant C | 4,801,312 | 603,417 |
| Events in quadrant D | 6,053,120 | 525,975 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16847 | 117 |
| B | 0 | 15622 | 126 |
| C | 0 | 19303 | 190 |
| D | 0 | 22966 | 188 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 144 | 0 |
| B | 0 | 143 | 0 |
| C | 0 | 144 | 0 |
| D | 0 | 144 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7027 | 278 | 3.956169% |
| B | 7021 | 213 | 3.033756% |
| C | 7009 | 385 | 5.492938% |
| D | 7003 | 868 | 12.394688% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7781 | 7070 | 89 | 89 | 1.14% | 1.26% |  |
| B | 7781 | 7068 | 51 | 51 | 0.66% | 0.72% |  |
| C | 7781 | 7067 | 183 | 183 | 2.35% | 2.59% |  |
| D | 7780 | 7063 | 641 | 641 | 8.24% | 9.08% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 14 | 381731 | 2010.11 | 767 | 746 | 189.5 |
| A | 0 | 8 | 359240 | 1891.44 | 767 | 746 | 189.5 |
| A | 0 | 250 | 103482 | 542.04 | 767 | 746 | 189.5 |
| B | 5 | 236 | 324338 | 1991.75 | 753 | 723 | 162.5 |
| B | 5 | 185 | 144436 | 884.51 | 753 | 723 | 162.5 |
| B | 7 | 252 | 38676 | 233.59 | 753 | 723 | 162.5 |
| C | 4 | 5 | 616242 | 3055.93 | 740 | 732 | 201.4 |
| C | 9 | 38 | 554004 | 2746.92 | 740 | 732 | 201.4 |
| C | 12 | 252 | 160838 | 794.91 | 740 | 732 | 201.4 |
| D | 15 | 94 | 1071536 | 5338.82 | 716 | 686 | 200.6 |
| D | 14 | 52 | 532419 | 2651.0 | 716 | 686 | 200.6 |
| D | 11 | 129 | 457704 | 2278.51 | 716 | 686 | 200.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
