| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_014T01_9000006528_54939cztM0_level2.fits | modeM0/AS1A14_014T01_9000006528_54939cztM0_level2_quad_clean.evt |
| Size (bytes) | 443,401,920 | 82,774,080 |
| Size | 422.9 MB | 78.9 MB |
| Events in quadrant A | 3,619,062 | 534,504 |
| Events in quadrant B | 2,642,111 | 604,608 |
| Events in quadrant C | 5,428,894 | 473,827 |
| Events in quadrant D | 4,264,797 | 481,434 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14941 | 1 |
| B | 0 | 12243 | 1 |
| C | 0 | 20270 | 5 |
| D | 0 | 16597 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 120 | 0 |
| B | 0 | 120 | 0 |
| C | 0 | 120 | 0 |
| D | 0 | 120 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5894 | 394 | 6.684764% |
| B | 5895 | 108 | 1.832061% |
| C | 5893 | 843 | 14.305108% |
| D | 5895 | 356 | 6.039016% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6844 | 5894 | 292 | 292 | 4.27% | 4.95% |  |
| B | 6845 | 5895 | 7 | 7 | 0.10% | 0.12% |  |
| C | 6845 | 5894 | 672 | 672 | 9.82% | 11.40% |  |
| D | 6845 | 5895 | 237 | 237 | 3.46% | 4.02% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 45 | 523726 | 3370.54 | 626 | 609 | 155.2 |
| A | 15 | 32 | 416816 | 2681.7 | 626 | 609 | 155.2 |
| A | 13 | 248 | 102893 | 659.04 | 626 | 609 | 155.2 |
| B | 0 | 182 | 60874 | 440.57 | 636 | 613 | 136.8 |
| B | 7 | 0 | 19062 | 134.88 | 636 | 613 | 136.8 |
| B | 7 | 252 | 17404 | 122.76 | 636 | 613 | 136.8 |
| C | 4 | 5 | 2099195 | 12955.47 | 591 | 585 | 162.0 |
| C | 12 | 252 | 700240 | 4319.22 | 591 | 585 | 162.0 |
| C | 13 | 3 | 94226 | 578.08 | 591 | 585 | 162.0 |
| D | 2 | 249 | 550394 | 3189.66 | 614 | 588 | 172.4 |
| D | 1 | 31 | 430411 | 2493.59 | 614 | 588 | 172.4 |
| D | 6 | 62 | 132598 | 765.85 | 614 | 588 | 172.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
