| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_022T16_9000006532_55127cztM0_level2.fits | modeM0/AS1A14_022T16_9000006532_55127cztM0_level2_quad_clean.evt |
| Size (bytes) | 509,221,440 | 92,874,240 |
| Size | 485.6 MB | 88.6 MB |
| Events in quadrant A | 4,314,230 | 614,580 |
| Events in quadrant B | 2,888,048 | 678,637 |
| Events in quadrant C | 3,555,557 | 588,850 |
| Events in quadrant D | 7,589,166 | 478,348 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17511 | 1 |
| B | 0 | 13627 | 1 |
| C | 0 | 15411 | 2 |
| D | 0 | 27092 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6474 | 207 | 3.197405% |
| B | 6474 | 75 | 1.158480% |
| C | 6473 | 147 | 2.270972% |
| D | 6474 | 1095 | 16.913809% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7614 | 6475 | 145 | 145 | 1.90% | 2.24% |  |
| B | 7614 | 6475 | 27 | 27 | 0.35% | 0.42% |  |
| C | 7613 | 6474 | 133 | 133 | 1.75% | 2.05% |  |
| D | 7614 | 6475 | 1160 | 1160 | 15.24% | 17.92% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 241 | 1068861 | 6276.02 | 674 | 657 | 170.2 |
| A | 0 | 8 | 377712 | 2215.31 | 674 | 657 | 170.2 |
| A | 12 | 115 | 208264 | 1219.75 | 674 | 657 | 170.2 |
| B | 2 | 249 | 111410 | 760.24 | 675 | 650 | 145.7 |
| B | 0 | 182 | 28263 | 189.53 | 675 | 650 | 145.7 |
| B | 5 | 185 | 21580 | 143.66 | 675 | 650 | 145.7 |
| C | 13 | 3 | 679294 | 3767.83 | 653 | 647 | 180.1 |
| C | 15 | 178 | 93995 | 518.27 | 653 | 647 | 180.1 |
| C | 6 | 223 | 78195 | 430.54 | 653 | 647 | 180.1 |
| D | 11 | 129 | 4982627 | 28626.69 | 611 | 582 | 174.0 |
| D | 5 | 173 | 44757 | 253.83 | 611 | 582 | 174.0 |
| D | 15 | 94 | 40090 | 227.01 | 611 | 582 | 174.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
