| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_022T16_9000006532_55185cztM0_level2.fits | modeM0/AS1A14_022T16_9000006532_55185cztM0_level2_quad_clean.evt |
| Size (bytes) | 400,697,280 | 99,806,400 |
| Size | 382.1 MB | 95.2 MB |
| Events in quadrant A | 3,635,705 | 651,350 |
| Events in quadrant B | 2,879,963 | 712,271 |
| Events in quadrant C | 3,499,138 | 621,794 |
| Events in quadrant D | 4,292,841 | 566,706 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15725 | 2 |
| B | 0 | 13867 | 2 |
| C | 0 | 15399 | 2 |
| D | 0 | 17927 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6742 | 124 | 1.839217% |
| B | 6742 | 35 | 0.519134% |
| C | 6742 | 106 | 1.572234% |
| D | 6742 | 335 | 4.968852% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7902 | 6744 | 66 | 66 | 0.84% | 0.98% |  |
| B | 7902 | 6744 | 2 | 2 | 0.03% | 0.03% |  |
| C | 7902 | 6744 | 85 | 85 | 1.08% | 1.26% |  |
| D | 7902 | 6744 | 262 | 262 | 3.32% | 3.88% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 78 | 414610 | 2369.89 | 705 | 690 | 174.7 |
| A | 4 | 249 | 214702 | 1225.32 | 705 | 690 | 174.7 |
| A | 0 | 8 | 187260 | 1068.2 | 705 | 690 | 174.7 |
| B | 10 | 247 | 37829 | 243.04 | 710 | 683 | 152.8 |
| B | 12 | 111 | 18397 | 115.9 | 710 | 683 | 152.8 |
| B | 14 | 111 | 17316 | 108.83 | 710 | 683 | 152.8 |
| C | 10 | 22 | 175723 | 923.41 | 691 | 686 | 189.6 |
| C | 1 | 16 | 141348 | 742.06 | 691 | 686 | 189.6 |
| C | 13 | 3 | 108731 | 569.99 | 691 | 686 | 189.6 |
| D | 2 | 249 | 1226202 | 6454.3 | 668 | 637 | 189.9 |
| D | 11 | 129 | 163859 | 859.59 | 668 | 637 | 189.9 |
| D | 12 | 6 | 49939 | 259.64 | 668 | 637 | 189.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
