| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_009T01_9000006534_55289cztM0_level2.fits | modeM0/AS1A14_009T01_9000006534_55289cztM0_level2_quad_clean.evt |
| Size (bytes) | 409,348,800 | 104,149,440 |
| Size | 390.4 MB | 99.3 MB |
| Events in quadrant A | 3,490,534 | 671,314 |
| Events in quadrant B | 3,427,221 | 724,878 |
| Events in quadrant C | 3,365,252 | 653,559 |
| Events in quadrant D | 4,305,807 | 599,687 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15999 | 2 |
| B | 0 | 15690 | 2 |
| C | 0 | 15580 | 2 |
| D | 0 | 17973 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7243 | 116 | 1.601546% |
| B | 7244 | 110 | 1.518498% |
| C | 7244 | 53 | 0.731640% |
| D | 7244 | 248 | 3.423523% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8873 | 7246 | 71 | 71 | 0.80% | 0.98% |  |
| B | 8874 | 7247 | 24 | 24 | 0.27% | 0.33% |  |
| C | 8874 | 7247 | 25 | 25 | 0.28% | 0.34% |  |
| D | 8874 | 7247 | 164 | 164 | 1.85% | 2.26% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 78 | 398558 | 2138.47 | 759 | 740 | 186.0 |
| A | 4 | 205 | 35843 | 188.7 | 759 | 740 | 186.0 |
| A | 0 | 8 | 34744 | 182.79 | 759 | 740 | 186.0 |
| B | 7 | 252 | 170616 | 1041.77 | 758 | 730 | 163.1 |
| B | 2 | 249 | 65049 | 394.41 | 758 | 730 | 163.1 |
| B | 0 | 199 | 52185 | 315.53 | 758 | 730 | 163.1 |
| C | 13 | 3 | 152023 | 731.61 | 751 | 742 | 206.8 |
| C | 12 | 250 | 114480 | 550.05 | 751 | 742 | 206.8 |
| C | 12 | 252 | 35795 | 169.52 | 751 | 742 | 206.8 |
| D | 7 | 70 | 560280 | 2685.37 | 735 | 702 | 208.4 |
| D | 11 | 129 | 467377 | 2239.54 | 735 | 702 | 208.4 |
| D | 2 | 31 | 136408 | 651.24 | 735 | 702 | 208.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
