| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_009T01_9000006534_55334cztM0_level2.fits | modeM0/AS1A14_009T01_9000006534_55334cztM0_level2_quad_clean.evt |
| Size (bytes) | 571,435,200 | 124,188,480 |
| Size | 545.0 MB | 118.4 MB |
| Events in quadrant A | 4,665,845 | 806,125 |
| Events in quadrant B | 4,074,814 | 864,835 |
| Events in quadrant C | 6,644,393 | 759,863 |
| Events in quadrant D | 5,095,677 | 727,786 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 176 | 0 |
| B | 0 | 176 | 0 |
| C | 0 | 176 | 0 |
| D | 0 | 176 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20346 | 1 |
| B | 0 | 18752 | 1 |
| C | 0 | 25770 | 2 |
| D | 0 | 21515 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8661 | 103 | 1.189239% |
| B | 8662 | 73 | 0.842761% |
| C | 8661 | 304 | 3.509987% |
| D | 8661 | 152 | 1.754994% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9091 | 8662 | 60 | 60 | 0.66% | 0.69% |  |
| B | 9092 | 8663 | 17 | 17 | 0.19% | 0.20% |  |
| C | 9091 | 8662 | 228 | 228 | 2.51% | 2.63% |  |
| D | 9091 | 8662 | 118 | 118 | 1.30% | 1.36% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 115 | 370596 | 1628.75 | 920 | 898 | 227.0 |
| A | 0 | 8 | 228912 | 1004.54 | 920 | 898 | 227.0 |
| A | 3 | 78 | 223192 | 979.34 | 920 | 898 | 227.0 |
| B | 0 | 199 | 239916 | 1205.8 | 918 | 883 | 198.2 |
| B | 7 | 252 | 67573 | 336.42 | 918 | 883 | 198.2 |
| B | 5 | 185 | 45814 | 226.65 | 918 | 883 | 198.2 |
| C | 9 | 38 | 2492805 | 10091.19 | 900 | 890 | 246.9 |
| C | 13 | 3 | 290848 | 1174.2 | 900 | 890 | 246.9 |
| C | 12 | 249 | 114517 | 460.14 | 900 | 890 | 246.9 |
| D | 11 | 129 | 423590 | 1659.69 | 901 | 864 | 254.7 |
| D | 3 | 12 | 265507 | 1039.03 | 901 | 864 | 254.7 |
| D | 11 | 176 | 196004 | 766.15 | 901 | 864 | 254.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
