| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_099T01_9000006536_55408cztM0_level2.fits | modeM0/AS1A14_099T01_9000006536_55408cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,401,713,280 | 178,110,720 |
| Size | 1.3 GB | 169.9 MB |
| Events in quadrant A | 7,952,846 | 1,304,600 |
| Events in quadrant B | 6,773,748 | 1,411,552 |
| Events in quadrant C | 6,790,396 | 1,261,720 |
| Events in quadrant D | 29,258,484 | 424,264 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 288 | 0 |
| B | 0 | 290 | 0 |
| C | 0 | 290 | 0 |
| D | 0 | 290 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 34497 | 9 |
| B | 0 | 31190 | 4 |
| C | 0 | 31327 | 4 |
| D | 0 | 96823 | 25 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 14342 | 393 | 2.740204% |
| B | 14345 | 193 | 1.345417% |
| C | 14345 | 131 | 0.913210% |
| D | 14344 | 9495 | 66.194925% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 14447 | 14346 | 301 | 301 | 2.08% | 2.10% |  |
| B | 14447 | 14347 | 86 | 86 | 0.60% | 0.60% |  |
| C | 14447 | 14347 | 84 | 84 | 0.58% | 0.59% |  |
| D | 14447 | 14347 | 8898 | 8898 | 61.59% | 62.02% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 159 | 1612579 | 4434.73 | 1475 | 1438 | 363.3 |
| A | 0 | 8 | 316757 | 867.93 | 1475 | 1438 | 363.3 |
| A | 4 | 3 | 80710 | 218.2 | 1475 | 1438 | 363.3 |
| B | 5 | 172 | 381319 | 1223.49 | 1467 | 1409 | 310.5 |
| B | 10 | 247 | 168297 | 537.46 | 1467 | 1409 | 310.5 |
| B | 7 | 0 | 154770 | 493.9 | 1467 | 1409 | 310.5 |
| C | 13 | 3 | 591797 | 1487.75 | 1456 | 1440 | 396.8 |
| C | 1 | 241 | 295596 | 741.3 | 1456 | 1440 | 396.8 |
| C | 12 | 252 | 42117 | 102.51 | 1456 | 1440 | 396.8 |
| D | 11 | 129 | 24705251 | 109044.12 | 794 | 759 | 226.6 |
| D | 11 | 176 | 372926 | 1642.72 | 794 | 759 | 226.6 |
| D | 2 | 249 | 234178 | 1030.3 | 794 | 759 | 226.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
