| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_021T06_9000006538cztM0_level2.fits | modeM0/AS1A14_021T06_9000006538cztM0_level2_quad_clean.evt |
| Size (bytes) | 4,600,895,040 | 2,237,500,800 |
| Size | 4.3 GB | 2.1 GB |
| Events in quadrant A | 25,501,908 | 6,227,408 |
| Events in quadrant B | 24,656,443 | 6,887,124 |
| Events in quadrant C | 24,500,180 | 5,850,306 |
| Events in quadrant D | 21,192,614 | 5,339,856 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 770 | 0 |
| B | 0 | 771 | 0 |
| C | 0 | 771 | 0 |
| D | 0 | 771 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1775943 | 0 |
| B | 0 | 1366455 | 0 |
| C | 0 | 1689949 | 0 |
| D | 0 | 1830813 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12788 | 0 |
| B | 0 | 12784 | 0 |
| C | 0 | 12788 | 0 |
| D | 0 | 12784 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 634346 | 41613 | 6.559985% |
| B | 634279 | 9687 | 1.527246% |
| C | 634344 | 35475 | 5.592392% |
| D | 634324 | 46031 | 7.256702% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 631164 | 534532 | 0 | 0 | 0.00% | 0.00% |  |
| B | 631164 | 534676 | 0 | 0 | 0.00% | 0.00% |  |
| C | 631164 | 533912 | 0 | 0 | 0.00% | 0.00% |  |
| D | 631164 | 534286 | 0 | 0 | 0.00% | 0.00% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 188 | 28415 | 9.87 | 6706 | 6178 | 2253.6 |
| A | 9 | 255 | 25872 | 8.74 | 6706 | 6178 | 2253.6 |
| A | 14 | 204 | 23501 | 7.69 | 6706 | 6178 | 2253.6 |
| B | 2 | 9 | 28596 | 14.91 | 6508 | 6166 | 1504.8 |
| B | 2 | 8 | 25931 | 13.13 | 6508 | 6166 | 1504.8 |
| B | 3 | 25 | 20396 | 9.46 | 6508 | 6166 | 1504.8 |
| C | 15 | 175 | 20222 | 6.31 | 6539 | 5954 | 2262.5 |
| C | 15 | 127 | 19480 | 5.98 | 6539 | 5954 | 2262.5 |
| C | 2 | 31 | 19375 | 5.93 | 6539 | 5954 | 2262.5 |
| D | 6 | 218 | 27015 | 10.52 | 6051 | 5353 | 2059.3 |
| D | 15 | 11 | 20220 | 7.22 | 6051 | 5353 | 2059.3 |
| D | 3 | 30 | 19973 | 7.1 | 6051 | 5353 | 2059.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
