| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_021T06_9000006538_55543cztM0_level2.fits | modeM0/AS1A14_021T06_9000006538_55543cztM0_level2_quad_clean.evt |
| Size (bytes) | 466,888,320 | 89,389,440 |
| Size | 445.3 MB | 85.2 MB |
| Events in quadrant A | 2,787,405 | 612,501 |
| Events in quadrant B | 4,118,437 | 611,790 |
| Events in quadrant C | 3,379,793 | 586,856 |
| Events in quadrant D | 6,477,594 | 430,168 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13501 | 1 |
| B | 0 | 17383 | 1 |
| C | 0 | 15135 | 1 |
| D | 0 | 24329 | 6 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6670 | 5 | 0.074963% |
| B | 6671 | 461 | 6.910508% |
| C | 6671 | 38 | 0.569630% |
| D | 6670 | 1479 | 22.173913% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7575 | 6671 | 3 | 3 | 0.04% | 0.04% |  |
| B | 7576 | 6672 | 403 | 403 | 5.32% | 6.04% |  |
| C | 7576 | 6672 | 48 | 48 | 0.63% | 0.72% |  |
| D | 7574 | 6670 | 1464 | 1464 | 19.33% | 21.95% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 3 | 72983 | 434.63 | 673 | 657 | 166.4 |
| A | 0 | 8 | 23403 | 136.69 | 673 | 657 | 166.4 |
| A | 15 | 32 | 19397 | 112.61 | 673 | 657 | 166.4 |
| B | 5 | 236 | 1154253 | 8324.74 | 653 | 631 | 138.6 |
| B | 7 | 0 | 134471 | 965.81 | 653 | 631 | 138.6 |
| B | 10 | 247 | 65155 | 465.62 | 653 | 631 | 138.6 |
| C | 12 | 250 | 500697 | 2768.01 | 655 | 649 | 180.7 |
| C | 13 | 3 | 118021 | 649.71 | 655 | 649 | 180.7 |
| C | 15 | 178 | 110434 | 607.71 | 655 | 649 | 180.7 |
| D | 7 | 70 | 3543404 | 21550.32 | 575 | 548 | 164.4 |
| D | 11 | 129 | 200669 | 1217.29 | 575 | 548 | 164.4 |
| D | 2 | 172 | 138172 | 837.13 | 575 | 548 | 164.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
