| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_021T06_9000006538_55550cztM0_level2.fits | modeM0/AS1A14_021T06_9000006538_55550cztM0_level2_quad_clean.evt |
| Size (bytes) | 464,198,400 | 98,879,040 |
| Size | 442.7 MB | 94.3 MB |
| Events in quadrant A | 3,737,820 | 635,690 |
| Events in quadrant B | 5,161,805 | 674,737 |
| Events in quadrant C | 3,414,922 | 617,590 |
| Events in quadrant D | 4,327,404 | 580,901 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16452 | 1 |
| B | 0 | 20421 | 1 |
| C | 0 | 15050 | 1 |
| D | 0 | 17800 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6961 | 315 | 4.525212% |
| B | 6961 | 455 | 6.536417% |
| C | 6961 | 62 | 0.890677% |
| D | 6961 | 166 | 2.384715% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7815 | 6960 | 265 | 265 | 3.39% | 3.81% |  |
| B | 7816 | 6962 | 396 | 396 | 5.07% | 5.69% |  |
| C | 7816 | 6962 | 30 | 30 | 0.38% | 0.43% |  |
| D | 7816 | 6962 | 143 | 143 | 1.83% | 2.05% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 115 | 775971 | 4404.33 | 711 | 691 | 176.0 |
| A | 15 | 32 | 96368 | 543.54 | 711 | 691 | 176.0 |
| A | 4 | 159 | 28167 | 156.09 | 711 | 691 | 176.0 |
| B | 4 | 206 | 2149519 | 14745.21 | 693 | 667 | 145.7 |
| B | 0 | 173 | 76623 | 521.2 | 693 | 667 | 145.7 |
| B | 4 | 169 | 61979 | 420.72 | 693 | 667 | 145.7 |
| C | 9 | 38 | 218514 | 1140.23 | 694 | 687 | 191.0 |
| C | 1 | 16 | 217952 | 1137.29 | 694 | 687 | 191.0 |
| C | 15 | 147 | 75866 | 393.53 | 694 | 687 | 191.0 |
| D | 11 | 129 | 715869 | 3718.2 | 692 | 661 | 192.4 |
| D | 2 | 249 | 431260 | 2238.59 | 692 | 661 | 192.4 |
| D | 8 | 160 | 144514 | 747.86 | 692 | 661 | 192.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
