| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_099T04_9000006540_55696cztM0_level2.fits | modeM0/AS1A14_099T04_9000006540_55696cztM0_level2_quad_clean.evt |
| Size (bytes) | 463,011,840 | 103,029,120 |
| Size | 441.6 MB | 98.3 MB |
| Events in quadrant A | 4,592,207 | 641,687 |
| Events in quadrant B | 3,192,896 | 721,662 |
| Events in quadrant C | 3,859,752 | 648,474 |
| Events in quadrant D | 4,927,190 | 600,103 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19002 | 2 |
| B | 0 | 15173 | 2 |
| C | 0 | 17153 | 2 |
| D | 0 | 19925 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7291 | 442 | 6.062269% |
| B | 7292 | 161 | 2.207899% |
| C | 7292 | 219 | 3.003291% |
| D | 7292 | 271 | 3.716402% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7721 | 7292 | 323 | 323 | 4.18% | 4.43% |  |
| B | 7722 | 7292 | 12 | 12 | 0.16% | 0.16% |  |
| C | 7722 | 7293 | 159 | 159 | 2.06% | 2.18% |  |
| D | 7722 | 7292 | 219 | 219 | 2.84% | 3.00% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 115 | 1063678 | 5637.84 | 770 | 749 | 188.5 |
| A | 3 | 95 | 250005 | 1322.07 | 770 | 749 | 188.5 |
| A | 8 | 249 | 78527 | 412.54 | 770 | 749 | 188.5 |
| B | 4 | 206 | 35482 | 209.45 | 767 | 739 | 165.9 |
| B | 2 | 249 | 26699 | 156.5 | 767 | 739 | 165.9 |
| B | 4 | 190 | 26275 | 153.95 | 767 | 739 | 165.9 |
| C | 13 | 3 | 265293 | 1287.56 | 747 | 740 | 205.5 |
| C | 12 | 112 | 206598 | 1001.9 | 747 | 740 | 205.5 |
| C | 6 | 223 | 110334 | 533.39 | 747 | 740 | 205.5 |
| D | 11 | 129 | 1744320 | 8227.35 | 748 | 714 | 211.9 |
| D | 8 | 245 | 94764 | 443.78 | 748 | 714 | 211.9 |
| D | 7 | 129 | 91025 | 426.14 | 748 | 714 | 211.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
