| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_099T04_9000006540_55705cztM0_level2.fits | modeM0/AS1A14_099T04_9000006540_55705cztM0_level2_quad_clean.evt |
| Size (bytes) | 601,614,720 | 91,664,640 |
| Size | 573.7 MB | 87.4 MB |
| Events in quadrant A | 8,662,739 | 479,200 |
| Events in quadrant B | 2,897,568 | 687,272 |
| Events in quadrant C | 4,003,215 | 615,617 |
| Events in quadrant D | 6,181,410 | 521,929 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 30435 | 2 |
| B | 0 | 13857 | 2 |
| C | 0 | 16462 | 2 |
| D | 0 | 23227 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6762 | 1858 | 27.477078% |
| B | 6762 | 26 | 0.384502% |
| C | 6762 | 63 | 0.931677% |
| D | 6762 | 838 | 12.392783% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7817 | 6762 | 1595 | 1595 | 20.40% | 23.59% |  |
| B | 7817 | 6762 | 6 | 6 | 0.08% | 0.09% |  |
| C | 7817 | 6763 | 50 | 50 | 0.64% | 0.74% |  |
| D | 7817 | 6763 | 849 | 849 | 10.86% | 12.55% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 32 | 5768512 | 37910.06 | 616 | 599 | 152.1 |
| A | 0 | 8 | 146484 | 958.84 | 616 | 599 | 152.1 |
| A | 8 | 249 | 112420 | 734.95 | 616 | 599 | 152.1 |
| B | 0 | 171 | 42517 | 276.59 | 704 | 678 | 151.3 |
| B | 9 | 251 | 20034 | 127.96 | 704 | 678 | 151.3 |
| B | 12 | 111 | 18763 | 119.56 | 704 | 678 | 151.3 |
| C | 1 | 16 | 979204 | 5166.34 | 695 | 687 | 189.4 |
| C | 6 | 223 | 128760 | 676.19 | 695 | 687 | 189.4 |
| C | 12 | 250 | 64693 | 337.93 | 695 | 687 | 189.4 |
| D | 11 | 129 | 3378420 | 18067.7 | 656 | 626 | 187.0 |
| D | 7 | 129 | 93074 | 494.5 | 656 | 626 | 187.0 |
| D | 3 | 12 | 56859 | 300.79 | 656 | 626 | 187.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
