| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_099T04_9000006540_55723cztM0_level2.fits | modeM0/AS1A14_099T04_9000006540_55723cztM0_level2_quad_clean.evt |
| Size (bytes) | 702,979,200 | 75,608,640 |
| Size | 670.4 MB | 72.1 MB |
| Events in quadrant A | 6,746,649 | 508,947 |
| Events in quadrant B | 2,783,176 | 633,971 |
| Events in quadrant C | 5,744,710 | 443,839 |
| Events in quadrant D | 10,275,852 | 277,888 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24265 | 1 |
| B | 0 | 12775 | 1 |
| C | 0 | 21290 | 1 |
| D | 0 | 34666 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6077 | 1005 | 16.537765% |
| B | 6078 | 74 | 1.217506% |
| C | 6078 | 1428 | 23.494571% |
| D | 6078 | 3130 | 51.497203% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7227 | 6078 | 845 | 845 | 11.69% | 13.90% |  |
| B | 7228 | 6079 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7228 | 6078 | 961 | 961 | 13.30% | 15.81% |  |
| D | 7228 | 6079 | 2697 | 2697 | 37.31% | 44.37% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 32 | 3392389 | 22297.1 | 616 | 600 | 152.1 |
| A | 7 | 64 | 383426 | 2516.64 | 616 | 600 | 152.1 |
| A | 4 | 249 | 264331 | 1733.73 | 616 | 600 | 152.1 |
| B | 4 | 206 | 108118 | 770.72 | 648 | 623 | 139.5 |
| B | 0 | 199 | 41691 | 294.45 | 648 | 623 | 139.5 |
| B | 7 | 0 | 38637 | 272.55 | 648 | 623 | 139.5 |
| C | 15 | 199 | 3061597 | 21309.81 | 518 | 514 | 143.6 |
| C | 14 | 96 | 171163 | 1187.98 | 518 | 514 | 143.6 |
| C | 6 | 223 | 147850 | 1025.68 | 518 | 514 | 143.6 |
| D | 11 | 129 | 8300391 | 64378.13 | 452 | 430 | 128.9 |
| D | 8 | 245 | 84742 | 653.96 | 452 | 430 | 128.9 |
| D | 2 | 31 | 40562 | 311.28 | 452 | 430 | 128.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
