| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_099T04_9000006540_55737cztM0_level2.fits | modeM0/AS1A14_099T04_9000006540_55737cztM0_level2_quad_clean.evt |
| Size (bytes) | 651,574,080 | 78,289,920 |
| Size | 621.4 MB | 74.7 MB |
| Events in quadrant A | 12,284,693 | 220,874 |
| Events in quadrant B | 3,438,197 | 628,823 |
| Events in quadrant C | 4,217,610 | 579,897 |
| Events in quadrant D | 3,709,912 | 519,652 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 40645 | 1 |
| B | 0 | 14708 | 1 |
| C | 0 | 16697 | 3 |
| D | 0 | 15373 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6034 | 4037 | 66.904209% |
| B | 6034 | 222 | 3.679151% |
| C | 6034 | 111 | 1.839576% |
| D | 6034 | 300 | 4.971826% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7204 | 6034 | 3458 | 3458 | 48.00% | 57.31% |  |
| B | 7204 | 6035 | 90 | 90 | 1.25% | 1.49% |  |
| C | 7204 | 6035 | 38 | 38 | 0.53% | 0.63% |  |
| D | 7204 | 6035 | 134 | 134 | 1.86% | 2.22% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 32 | 9308640 | 95951.18 | 391 | 380 | 97.0 |
| A | 4 | 249 | 874722 | 9012.87 | 391 | 380 | 97.0 |
| A | 12 | 115 | 251386 | 2587.41 | 391 | 380 | 97.0 |
| B | 4 | 206 | 665803 | 4787.16 | 646 | 623 | 139.0 |
| B | 5 | 172 | 170677 | 1223.84 | 646 | 623 | 139.0 |
| B | 10 | 247 | 17752 | 123.27 | 646 | 623 | 139.0 |
| C | 9 | 38 | 1195589 | 6781.48 | 639 | 633 | 176.2 |
| C | 14 | 96 | 217975 | 1233.43 | 639 | 633 | 176.2 |
| C | 13 | 3 | 182697 | 1033.23 | 639 | 633 | 176.2 |
| D | 11 | 129 | 1212502 | 6886.61 | 620 | 590 | 176.0 |
| D | 5 | 173 | 41528 | 232.63 | 620 | 590 | 176.0 |
| D | 2 | 31 | 40476 | 226.65 | 620 | 590 | 176.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
