| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_127T10_9000006542_55789cztM0_level2.fits | modeM0/AS1A14_127T10_9000006542_55789cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,598,716,800 | 246,041,280 |
| Size | 1.5 GB | 234.6 MB |
| Events in quadrant A | 19,348,415 | 1,461,946 |
| Events in quadrant B | 9,340,266 | 1,811,366 |
| Events in quadrant C | 8,285,621 | 1,658,827 |
| Events in quadrant D | 20,777,257 | 1,242,964 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 70246 | 4 |
| B | 0 | 39989 | 3 |
| C | 0 | 39309 | 3 |
| D | 0 | 74513 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 374 | 0 |
| B | 0 | 374 | 0 |
| C | 0 | 374 | 0 |
| D | 0 | 374 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 18481 | 2741 | 14.831449% |
| B | 18481 | 362 | 1.958768% |
| C | 18482 | 163 | 0.881939% |
| D | 18482 | 3773 | 20.414457% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 19721 | 18484 | 2100 | 2100 | 10.65% | 11.36% |  |
| B | 19721 | 18484 | 27 | 27 | 0.14% | 0.15% |  |
| C | 19722 | 18485 | 70 | 70 | 0.35% | 0.38% |  |
| D | 19722 | 18485 | 2967 | 2967 | 15.04% | 16.05% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 32 | 7517858 | 16160.44 | 1874 | 1823 | 465.1 |
| A | 12 | 115 | 2653768 | 5702.02 | 1874 | 1823 | 465.1 |
| A | 8 | 192 | 721179 | 1546.71 | 1874 | 1823 | 465.1 |
| B | 5 | 172 | 645485 | 1517.11 | 1965 | 1891 | 424.2 |
| B | 7 | 0 | 597448 | 1403.88 | 1965 | 1891 | 424.2 |
| B | 0 | 199 | 105489 | 244.21 | 1965 | 1891 | 424.2 |
| C | 13 | 3 | 409836 | 771.79 | 1941 | 1924 | 528.5 |
| C | 12 | 250 | 94770 | 175.67 | 1941 | 1924 | 528.5 |
| C | 6 | 223 | 57755 | 105.63 | 1941 | 1924 | 528.5 |
| D | 11 | 129 | 9193986 | 18507.81 | 1759 | 1681 | 496.7 |
| D | 8 | 245 | 2060399 | 4145.03 | 1759 | 1681 | 496.7 |
| D | 10 | 181 | 1602781 | 3223.66 | 1759 | 1681 | 496.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
